Supplemental Information - Keithley System SourceMeter 2601B Instrument Specifications

Models 2601B, 2602B and 2604B System SourceMeter

SUPPLEMENTAL INFORMATION

Front-panel interface
Display
Keypad operations
Programming
Minimum user memory
available
Test Script Builder
®
TSP Express (embedded)
Software interface
Specifications are subject to change without notice
10 of 13
®
Instrument Specifications
Two-line vacuum fluorescent display (VFD) with keypad and navigation wheel

Show error messages and user-defined messages

Display source and limit settings

Show current and voltage measurements

View measurements stored in dedicated reading buffers

Change host interface settings

Save and restore instrument setups

Load and run factory and user-defined test scripts that prompt for input and send
results to the display

Store measurements into dedicated reading buffers
Embedded Test Script Processor (TSP
interface:

Responds to individual instrument control commands

Responds to high-speed test scripts comprised of remote commands and test script
language (TSL) statements (for example, branching, looping, and math)

Able to execute high-speed test scripts stored in memory without host intervention
16 MB (approximately 250,000 lines of TSP code)
Integrated development environment for building, running, and managing TSP scripts;
includes an instrument console for interactive communication with any TSP-enabled
instrument
Requires:

VISA (NI-VISA included on the Product Information CD-ROM)
 ®
Microsoft .NET Framework (included on the Product Information CD-ROM)

Keithley I/O Layer (included on the Product Information CD-ROM)
 ®
Intel Pentium III 800 MHz or faster personal computer
 ® ®
Microsoft Windows 2000, XP, Vista
Tool that allows you to quickly and easily perform common I-V tests without programming
or installing software
To run TSP Express, you need:

Java™ Platform, Standard Edition 6 or 7
 ®
Microsoft Internet Explorer
browser
TSP™ Express (embedded), direct GPIB/VISA, read/write with Microsoft
® ®
Visual C/C++ , Visual C# , LabVIEW™, CEC TestPoint™ Data Acquisition Software
Package, NI LabWindows™/CVI, and so on.
®
) scripting engine is accessible from any host
®
, or 7
® ® ®
, Mozilla Firefox , or another Java-compatible web
SPEC-2602B Rev. B / February 2014
® ®
Visual Basic ,
