General Specifications - Keithley System SourceMeter 2601B Instrument Specifications

Models 2601B, 2602B and 2604B System SourceMeter

GENERAL SPECIFICATIONS

IEEE-488
RS-232
Ethernet
LXI compliance
24
Expansion interface
USB Control (Rear)
USB File System (Front)
Power supply
Cooling
Warranty
EMC
Safety
Environment
Dimensions
Weight
24
TSP-Link is not available with the Model 2604B.
Specifications are subject to change without notice
12 of 13
®
Instrument Specifications
IEEE Std 488.1 compliant. Supports IEEE Std 488.2 common commands and status
model topology

Baud rates from 300 bps to 115,200 bps

Programmable number of data bits, parity type, and flow control (RTS/CTS hardware
or none)

When not programmed as the active host interface, the Models 2601B, 2602B and
2604B can use the RS-232 interface to control other instruments
RJ-45 connector, LXI version 1.4 Core 2011, 10/100BaseT, Auto-MDIX
LXI version 1.4 Core 2011
 ®
The TSP-Link expansion interface allows TSP-enabled instruments to trigger and
communicate with each other

Cable type: Category 5e or higher LAN crossover cable

9.84 ft (3 m) maximum between each TSP-enabled instrument
USB 2.0 Device: USB-TMC488 protocol
USB 2.0 Host: Mass storage class device
100 V to 240 V AC, 50 Hz or 60 Hz (auto sensing), 240 VA maximum
Forced air; side intake and rear exhaust. One side must be unobstructed when rack
mounted.
1 year
Conforms to European Union EMC Directive
NRTL listed to UL61010-1:2008 and CSA C22.2 No. 61010-1
Conforms to European Union Low Voltage Directive
For indoor use only
Altitude: Maximum 6562 ft (2000 m) above sea level
Operating: 0 °C to 50 °C, 70 % relative humidity up to 35 °C. Derate 3 % relative
humidity/°C, 35 °C to 50 °C
Storage: -25 °C to 65 °C
Rack mount: 3.5 in. high × 8.4 in. wide × 17.5 in. deep (89 mm × 213 mm × 460 mm)
Bench configuration (with handle and feet): 4.1 in. high × 9.4 in. wide × 17.5 in. deep
(104 mm × 238 mm × 460 mm)
2601B: 10.4 lb (4.75 kg)
2602B and 2604B: 12.0 lb (5.50 kg)
SPEC-2602B Rev. B / February 2014
