ADXL180

SPECIFICATIONS

T = −40°C to +125°C, V − V
A BP
Table 1.
1
Parameter
SENSOR
Scale Factor
50 g Range
8-Bit Data
10-Bit Data
100 g Range
8-Bit Data
10-Bit Data
150 g Range
8-Bit Data
10-Bit Data
200 g Range
8-Bit Data
10-Bit Data
250 g Range
8-Bit Data
10-Bit Data
350 g Range
8-bit Data
10-bit Data
500 g Range
8-Bit Data
10-Bit Data
Offset
8-Bit Data
10-Bit Data
Noise (Peak-to-Peak)
8-Bit Data
10-Bit Data
Self Test
Amplitude
Internal Self-Test Limit
Nonlinearity
Cross-Axis Sensitivity
Resonant Frequency
Q
LOW-PASS FILTER
Frequency Response
Pass Band
−3 dB Frequency
−3 dB Frequency
−3 dB Frequency
−3 dB Frequency
AUTO-ZERO
Update Rate
Slow Mode
Fast Mode
= 5.0 V to 14.5 V, f = 400 Hz, acceleration = 0 g, unless otherwise noted.
BN LP
Symbol Min Typ
0.465 0.50
0.116 0.1250
0.930 1.00
0.233 0.2500
1.395 1.50
0.349 0.3750
1.860 2.00
0.465 0.5000
2.325 2.50
0.581 0.625
3.255 3.50
0.830 0.8925
4.650 5.00
1.163 1.2500
−12
−48
2
20 25
20
0.2
−5
12.8
1.5
Third-order
Bessel
f
LP
670 800
335 400
167.5 200
83.75 100
5.0
0.5
Max Unit
0.535 g/LSB
0.134 g/LSB
1.070 g/LSB
0.268 g/LSB
1.605 g/LSB
0.401 g/LSB
2.140 g/LSB
0.535 g/LSB
2.675 g/LSB
0.669 g/LSB
3.745 g/LSB
0.955 g/LSB
5.350 g/LSB
1.338 g/LSB
+11 LSB
+47 LSB
2 LSB
3 LSB
30 g
30 g
2 %
+5 %
kHz
880 Hz
440 Hz
220 Hz
110 Hz
sec/LSB
sec/LSB
Rev. 0 | Page 4 of 56
Test Conditions/Comments
Measurement frequency: 100 Hz
See Table 37
All ranges, auto-zero disabled
50 g range
10 Hz to 400 Hz
10 Hz to 400 Hz
STI enabled, see Table 35
Of full-scale range
Programmable, see Table 38
10-bit LSB
10-bit LSB
