ADXL180
8-Bit Data
Decimal Hex Decimal
−126 0x82 −504
−127 0x81 −508
−128 0x80 −512
Table 31. Phase 2 Mode 2 Delimiter Coding
Range State Vector Code
50 g 001b
100 g 001b
150 g 001b
200 g 001b
250 g 001b
350 g 001b
500 g 001b
10-Bit Data
Hex Data Type
0x208 Undefined
0x204 Undefined
0x200 Status code
Rev. 0 | Page 32 of 56
Description
Unused
Unused
±100 g measurement range
8-Bit Data
Decimal Hex
−125 0x83
−128 0x80
−125 0x83
−125 0x83
−122 0x86
−125 0x83
−125 0x83
10-Bit Data
Decimal Hex
−500 0x20C
−512 0x200
−500 0x20C
−500 0x20C
−488 0x218
−500 0x20C
−500 0x20C
