Technical Manual Taster BE-TA55
6.4 4‐Bit Dim command
The following chart describes the 4‐Bit dimming command:
Decimal Hexadecimal
0 0
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
10 A
11 B
12 C
13 D
14 E
15 F
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
58
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Binaer Dim command
0000 Stop
0001 100% Darker
0010 50% Darker
0011 25% Darker
0100 12,5% Darker
0101 6,25% Darker
0110 3,13% Darker
0111 1,56% Darker
1000 Stop
1001 100% Brighter
1010 50% Brighter
1011 25% Brighter
1100 12,5% Brighter
1101 6,25% Brighter
1110 3,13% Brighter
1111 1,56% Brighter
