Technical Manual Taster BE-TA55
To be sure that the push button toggles at every switching process, you have to connect the status
object of the push button "Value for toggle" with the status object of the actuator. When the push
button should work without an actuator, the object has to be connected to the switching object
"switch". The connection is important, because the push button cannot invert the signal, when it
does not know its current state.
By undocking this communication object, you have more choices to program the push button. So you
can use the object "Value for toggle" for visualizations or additional functions and you will be more
free in design your project.
So you have for example the option to visualize the switching process by connecting the status‐object
to a switching object of a LED or something else.
