MDT Technologies BE-TA5502.01 Technical Manual page 30

Technical Manual Taster BE-TA55
4.5.1.5 Send value with on/off delay
The following setting options are available at the function "Send value with on/off delay":
ETS‐text
Delay time
Chart 25: Parameter Send value with delay
The sub‐function "Send value with on/off delay" allows that the push button sends its value after a
parameterized time. At the on‐delay, the time starts when the associated button was switched on
and at the off‐delay, the time starts when the associated button was switched off. The push button
sends always its current value at this function. If the value changes before the time ran out, the on‐
delay will expire. For example, when an input with a parameterized on‐delay is switched off, before it
was switched on, the input remains off.
The following diagram describes the sub‐function „Send value with on‐delay":
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1
30
Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
Dynamic range
[default value]
0‐60min
[1s]
comment
Adjustment of the delay time
for the sending process
