Upper Left & Lower Left
STEP 01
Bracket Installation
E
4X
G
4X
There are 3 types of standoffs. You tell them from
the length, Long ones: 40mm, Medium ones:
25mm, short ones: 8mm
E
G
G
E
10mm Standoff
G
E
40mm Standoff
G
E
25mm Standoff
40mm Standoff
10mm Standoff
40mm Standoff
Please make sure the distance from
the edge of the holes on the PICE
riser before insatlling the 25mm GPU
standoffs.
25mm Standoff
40mm Standoff
