- Page 1 Version 2.0 A60 PLUS INSTALLATION GUIDE...
- Page 2 SCREWS LIST / 螺絲盒列表 A1 Plastic Pad/墊片 x6 Thumb Screw Screws for Radiator Screws for PSU M3 T type Nut A2 Standoff/銅柱 x6 手擰螺絲 冷排螺絲 電源螺絲 M3 T型螺母 M4x14mm M4x8mm M3x8mm M3x5mm M3x5mm...
- Page 3 Aluminum Frame Screw Installation 螺絲 鋁框架安裝說明 Acrylic Panel 壓克力板 螺母 Please read the “Aluminum Frame installation”before assembling this case 安裝前請務必先理解鋁框架如何安裝...
- Page 4 STEP 01 Aluminum Frame Installation 安裝機身鋁框架 320mm 320mm 150mm 215mm 320mm 320mm...
- Page 5 STEP 02 HDD Bracket Installation 安裝硬碟支架到右側鋁框架 150mm...
- Page 6 STEP 03 Back Panel Installation 安裝左側框架及右側框架後背板...
- Page 7 STEP 04 Install the PSU Metal Bracket on the Front Panel 安裝電源支架到前面板...
- Page 8 STEP 05 Install the ( 1 )USB 3.0 Cable and ( 2 )Power Switch on the front panel first, then install the ( 3 )front panel on the case 安裝( 1 )前置雙USB 3.0 及 ( 2 )電源開關到前面板，然後再安裝( 3 )前面板到機身框架上...
- Page 9 STEP 06 Install the Standoff and Plastic Pad on the M/B Metal Bracket 安裝銅柱及墊片到主機板鐵支架...
- Page 10 STEP 07 M/B Metal Bracket installation 安裝主機板鐵支架...
- Page 11 STEP 08 Highly recommend to install the CPU cooler (AIO CPU cooler)before installing the motherboard. M/B installation 建議先安裝CPU散熱器(包含一體 安裝主機板 水冷頭)，再安裝主機板.
- Page 12 STEP 09 Power Supply Installation 安裝電源供應器...
- Page 13 STEP 10 Power Extension Cable and PCI-e Riser CableInstallation 安裝電源延長線及顯示卡延長線...
- Page 14 STEP 11 GPU Card Installation 安裝顯示卡...
- Page 15 STEP 12 Aluminum Frame Installation 安裝鋁框架...
- Page 16 STEP 13-1 Case Fan Installation 安裝機殼風扇...
- Page 17 STEP 13-2 Radiator Installation 安裝水冷冷排...
- Page 18 STEP 14 Top Panel Installation 安裝上面板...
- Page 19 STEP 15 2.5" SSD/HDD Installation 安裝2.5"硬碟...
- Page 20 Please complete the cable management STEP 16 before installing the bottom panel. 請先完成所有的整線後再安裝底蓋 Case Fan and Bottom Panel Installation There are two sides for the bottom panel, 安裝系統風扇(可選)及底蓋 one side with the countersunk holes needed to be toward to the outside. 底蓋有分正反面，沉孔的那一面朝外...
- Page 21 STEP 17 Footpad Installation on the Bottom Panel 安裝腳墊到底蓋...
- Page 22 STEP 18 Place the case in horizontal, then install the side panel 請將機殼平躺後再安裝側板 Side Panel Installation 安裝側板...
