Summary of Contents for Geeek A70 PRO
- Page 1 Version 1.0 - V2.0 A70 PRO INSTALLATION GUIDE 100421...
- Page 2 SCREWS LIST / 螺絲盒列表 M3x5mm M4 Thumb Screws Screws for Fan 6#32x10mm M3 Nut J1 M3x5mm J2 M3x5mm M4x14mm M4x8mm M3x8mm M3x5mm...
- Page 3 Aluminum Frame Screw Installation 螺絲 Acrylic Panel 壓克力板 鋁框架安裝說明 螺母 Please read the “Aluminum Frame installation”before assembling this case 安裝前請務必先理解鋁框架如何安裝...
- Page 4 STEP 01 Aluminum Frame Installation 安裝機身鋁框架...
- Page 5 STEP 02 Install the HDD Bracket to the right aluminum frame * If you do not need to install the 2.5” HDD, please skip this step 安裝硬碟支架到右側鋁框架 *如果不安裝2.5”硬碟可以略過此步驟...
- Page 6 STEP 03 Instasll the middle layer to the left aluminum frame 安裝中層到左側鋁框架...
- Page 7 STEP 04 Foodpad and Bottom Panel Installation 安裝底蓋及腳墊...
- Page 8 STEP 05 Back Panel Installation 安裝後面板...
- Page 9 STEP 06 Motherboard Installation 安裝主機板...
- Page 10 STEP 07 PCI-e Riser Cable Installation 安裝顯示卡延長線...
- Page 11 STEP 08 GPU Installation 安裝顯示卡...
- Page 12 STEP 09 - v1.0 Power Supply and HDMI extension cable Installation 安裝電源供應器及HDMI延長線...
- Page 13 STEP 09-1 - v2.0 Power Supply, HDMI extension cable and DP extension cable(Optional) Installation 安裝電源供應器,HDMI延長線及DP延長線(可選)
- Page 14 STEP 09-2 - v2.0 Power Supply, HDMI extension cable and DP extension cable(Optional) Installation 安裝電源供應器,HDMI延長線及DP延長線(可選)
- Page 15 STEP 10 - v1.0 Power Switch, USB 3.0 Cable and Top Panel Installation 安裝電源開關,USB 3.0連接線及上面板...
- Page 16 STEP 10-1 - v2.0 Power Switch and USB 3.0 Cable Installation 安裝電源開關及USB 3.0連接線...
- Page 17 STEP 10-2 - v2.0 Power Switch and USB 3.0 Cable Installation 安裝電源開關及USB 3.0連接線...
- Page 18 STEP 11 Fan and Fan Bracket Installation 安裝風扇及風扇支架...
- Page 19 STEP 12 Front Panel Installation 安裝前面板...
- Page 20 STEP 13 2.5” HDD and HDD Bracket Installation *If you do not need to install the 2.5” HDD, please skip this step 安裝2.5”硬碟及硬碟支架 *如果不安裝2.5”硬碟可以略過此步驟...
- Page 21 STEP 14 Side Panel Installation 安裝側板...
