- Page 1 Version 1.0 N500 LITE INSTALLATION GUIDE...
- Page 2 SCREWS LIST / 螺絲盒列表 A1 M3x5mm M4 Thumb Screw Screws for Fan Screws for PSU M3 T type Nut A2 M3x12mm M4 手擰螺絲 風扇螺絲 電源螺絲 M3 T型螺母 M4x14mm M4x8mm M3x8mm M3x5mm M3x5mm...
- Page 3 Aluminum Frame Screw Installation 螺絲 Acrylic Panel 壓克力板 鋁框架安裝說明 螺母 Please read the “Aluminum Frame installation”before assembling this case 安裝前請務必先理解鋁框架如何安裝...
- Page 4 STEP 01 Aluminum Frame Installation 安裝機身鋁框架...
- Page 5 STEP 02 HDD Bracket Installation 安裝硬碟支架到左側鋁框架...
- Page 6 STEP 03 M/B Bracket Installation 安裝主機板支架到右側鋁框架...
- Page 7 STEP 04 Back Panel Installation 安裝後背板...
- Page 8 Highly recommend to install the case fan STEP 05 before installing the footpad. 請先安裝機殼風扇再安裝 腳墊. Case Fan 、Foodpad and Bottom Panel Installation There are two sides for the bottom panel, 安裝風扇、腳墊及底蓋 one side with the countersunk holes needed to be toward to the outside. 底蓋有分正反面，沉孔的那一面朝外...
- Page 9 STEP 06 PSU Bracket Installation 安裝電源供應器支架...
- Page 10 STEP 07 PSU and Power Extension Cable Installation 安裝電源供應器及電源延長線...
- Page 11 Highly recommend to install the CPU STEP 08 cooler and ram before installing the motherboard. M/B installation 請先安裝 CPU散熱器及記憶體到主機 板. 安裝主機板...
- Page 12 STEP 09 Case Fan Installation 安裝機殼風扇...
- Page 13 STEP 10 GPU Card Installation 安裝顯示卡...
- Page 14 STEP 11 Top Panel Installation 安裝上面板...
- Page 15 STEP 12 Install the ( 1 )USB 3.0 Cable and ( 2 )Power Switch on the front panel first, then install the ( 3 )front panel on the case 安裝( 1 )前置USB 3.0 及 ( 2 )電源開關到前面板，然後再安裝( 3 )前面板...
- Page 16 STEP 13 2.5" SSD/HDD Installation 安裝2.5"硬碟...
- Page 17 STEP 14 Place the case in horizontal, then install the side panel 請將機殼平躺後再安裝側板 Side Panel Installation 安裝側板...
