Version 1.0
A60 PLUS INSTALLATION GUIDE

Advertisement

loading

Related Manuals for Geeek A60 PLUS

Summary of Contents for Geeek A60 PLUS

  • Page 1 Version 1.0 A60 PLUS INSTALLATION GUIDE...
  • Page 2 SCREWS LIST / 螺絲盒列表 A1 Plastic Pad/墊片 x6 Thumb Screw Screws for Radiator Screws for PSU M3 T type Nut A2 Standoff/銅柱 x6 手擰螺絲 冷排螺絲 電源螺絲 M3 T型螺母 M4x14mm M4x8mm M3x8mm M3x5mm M3x5mm...
  • Page 3 STEP 01 Aluminum Frame Installation 安裝鋁框架 320mm 320mm 150mm 215mm 320mm 320mm...
  • Page 4 STEP 02 HDD Bracket Installation 安裝硬碟支架到右側鋁框架 150mm...
  • Page 5 STEP 03 Rear Panel Installation 安裝左側及右側鋁框架後面板 215mm...
  • Page 6 STEP 04 Install the PSU Metal Bracket on the Front Panel 安裝電源鐵支架到前面板...
  • Page 7 STEP 05 Install the 1. USB Module and 2. Power Switch on the front panel. 安裝1.USB模組 及 2.電源開關到前 面板.
  • Page 8 STEP 06 If you use the SFX-L power supply, highly recommend to install the power supply right after finished the whole process for Step 05. Please Install the 1. USB Module and 2. refer to STEP 10 for the Power Supply Power Switch on the front panel.
  • Page 9 STEP 07 Install the Standoff and Plastic Pad on the M/B Metal Bracket 安裝銅柱及墊片到主機板鐵支架...
  • Page 10 STEP 08 M/B Metal Bracket installation 安裝主機板鐵支架...
  • Page 11 STEP 09 Highly recommend to install the CPU cooler (AIO CPU cooler)before installing the motherboard. M/B installation 安裝主機板前建議先安裝CPU散熱 器(一體水冷). 安裝主機板...
  • Page 12 STEP 10 Power Supply Installation 安裝電源供應器...
  • Page 13 STEP 11 Power Cable Installation 安裝電源延長線...
  • Page 14 STEP 12 Power Cable Installation 安裝電源延長線...
  • Page 15 STEP 13 GPU Card & GPU Power Cable Installation 安裝顯示卡及顯示卡電源...
  • Page 16 STEP 14 Aluminum Frame Installation 安裝鋁條...
  • Page 17 STEP 15-1 Case Fan Installation 安裝機殼風扇...
  • Page 18 STEP 15-2 Radiator Installation 安裝水冷冷排...
  • Page 19 STEP 16 Top Panel Installation 安裝上面板...
  • Page 20 STEP 17 2.5" SSD/HDD Installation 安裝2.5"硬碟...
  • Page 21 STEP 18 Please complete the cable management before installing the bottom panel Case Fan and Bottom panel 請先完成整線後再安裝底蓋 Installation 安裝機殼風扇及底蓋...
  • Page 22 STEP 19 Footpad Installation 安裝腳墊...
  • Page 23 STEP 19 Place the case in horizontal, then install the side panel Side Panel Installation 請將機殼平躺再行安裝側板 安裝側板...
