Receiver Wiring (Rf Models) - Danfoss TP5001 Range Installation Manual

Models with remote sensor inputs
Terminal block for remote control/sensing
is located on the circuit board above the
battery compartment.
GB
S1/D
S2/E
GR
TR
LV
LT
Confi gured for
remote room
UA
sensor or limit
sensor
RU
3.3 RX Receiver Wiring (RF models only)
RX1
ELECTRONICS
N L
1) For mains voltage operated systems link terminal 2 to mains live supply.
2) Power supply to unit must not be switched by timeswitch.
IMPORTANT - To ensure that the factory programmes are set
and the micro-computer is operating correctly it is essential
that you press and hold the RESET button before you begin any
commissioning or programming.
8
S1/D
S2/E
Window or
teleswitch
contact
(NO or NC)
Confi gured for
window contact or
other contact such
as teleswitch
1 2 3 4
ZONE
COM ZONE
1 OFF
1 ON
RX2 & RX3
ELECTRONICS
A B C 1 2 3 4 5 6
N L
COM
/D
/E
Remote
control
connections
S1/D
S2/E
Window
contact (NC)
Teleswitch
contact (NC)
Confi gured for
window contact
and other contact
such as teleswitch
TERMINAL 6
RX3 ONLY
ZONE ZONE
ZONE ZONE
1 ON 1 OFF 2 ON 3 ON
TP5001
