Danfoss TP5001 Range Installation Manual page 14

Option 81 - Thermstat calibration bias
This allows the thermostat calibration to be biased by
up to ±1.5°K. Press + until Option 81 is displayed, use V
and Λ to select required setting.
Setting
GB
Option 90 - Defi ne remote sensor type, "A" models only
GR
This allows type of remote sensor input type to be
defi ned. Press + until Option 90 is displayed, use V
and Λ to select required setting.
TR
Setting 0
Setting 1
LV
Setting 2
Setting 3
LT
UA
Option 93 - Set limit sensor set-point, "A" models only,
(option 90 set to 2)
This allows the thermostat limit sensor to be set,
RU
typical application is fl oor htg. Press + until Option
93 is displayed, use V and Λ to select required
setting. If the temperature sensed by the limit sensor exceeds the limit
setting the output will be turned off untill the temperature has dropped
by 2°C "F10" will fl ash in the display.
Setting
Option 94 - Confi gure digital input switch type, "A" models only,
(option 90 set to 3)
This allows switch type of digital input to be
confi gured. Press + until Option 94 is displayed, use
V and Λ to select required setting.
Setting 0
Setting 1
14
Any value between ±1.5 (Factory setting is 0°C)
No remote sensor fi tted (Factory setting)
Remote room or duct sensor fi tted, internal sensor disabled
Remote limit sensor fi tted, refer to option 93 to defi ne set-point
Confi gured as digital input for window, card reader or
teleswitch, refer to option 94 to defi ne o/c or s/c.
Any value between 20 - 50°C (Factory setting is 27°C)
Contacts NC, open circuit contact to force unit into
thermostat mode, short circuit contacts to return to normal
operation
Contacts NO, short circuit contacts to force unit into
thermostat mode, open circuit contacts to return to normal
operation (Factory setting)
TP5001
