4.1 Entering Installer Advanced Programming
mode
To access the Installer Advanced Programming Mode follow the
steps below:
a) Press and hold
GB
Programming, the display will change to fi gure opposite.
b) Press and hold
GR
Advanced Programming, the display will
change to fi gure opposite.
TR c) Use + and - keys to scroll backwards and
forwards between options then
to change the option settings. The fl ashing
LV
digit on the right hand of the display indicates
the number of the selected option. The large
LT
characters display the option value selected.
d) To return to RUN, press and hold PROG until colon blinks.
UA
Option 30 - Set upper limit of temperature range
This allows the upper limit of the thermostat
RU
setting range to be electronically limited. Press +
until Option 30 is displayed, use V and Λ to select
required setting.
Setting
Option 31 - Set lower limit of temperature range
This allows the lower limit of the thermostat setting
range to be electronically limited. Press + until Option
31 is displayed, use V and Λ to select required setting.
Setting
Option 32 - Enable Off at lower limit
This enables an OFF function to be selected if a set
point below the lower limit is selected. Press + until
Option 32 is displayed, use V and Λ to select required
setting.
Setting 0
Setting 1
10
V
and PROG for 3 seconds to enter User Advanced
V Λ
, and PROG for 5 seconds to enter Installer
40 - 5°C (Factory setting is 30°C)
5 - 40°C (Factory setting is 5°C)
Disabled
Enabled (factory setting)
V Λ
and keys
TP5001
