Functional Layout

Configuration Manager tasks are grouped into categories, which
can be accessed by clicking the tabs at the top of each page.
Each tab displays the available tasks in a horizontal menu at the
top of the page. You can click on these menu items and display
the specific configuration options.
A separate page appears for each task in the task bar.
The left-most task appears by default when you click on a new
tab. The same task may appear in more than one tab, when
appropriate. For example, the [Lan Config] task appears in both
the [LAN] tab and the [Routing] tab.

Commonly used buttons

The following buttons are used throughout the application.
Button
Submit
Refresh
This button stores in the temporary system memory any changes
you have made on the current page. See Committing your changes
on page 38 for instructions on how to store changes permanently.
This button displays the current page with updated statistics or
settings.
