Connect to a TripSaver II Controller Module
8 S&C Instruction Sheet 461-506

Connect to Device

To connect to a TripSaver II Controller Module, select Connection > Connect to
Device from the main menu or click the Connect to Device icon
toolbar. Make sure that the USB transceiver is already plugged into your computer.
Next, a Transceiver ID Request dialog
box will appear. Enter the Transceiver
ID of the TripSaver II Controller Module
you want to connect to, and click "OK" to
connect. The first 16 digits of the ID are
pre-typed. You only need to enter the last
16 digits.
During the connection process, a status
bar will be displayed. Wait about ten sec-
onds for the connection process to finish,
or click "Cancel" to cancel the connection
process.
You will be able to see the Status Screen
after your TripSaver II Controller Module
is successfully connected. Now, you can
view existing settings, status information,
and event logs of the TripSaver II Controller
Module, or apply new settings to the device.
Step 4
Enter last 16 digits here
in the quick access
