SMC Networks SMC91C95 Product Manual page 55

Table 10 - PCMCIA EEPROM to SRAM Memory Map
ATTRIBUTE MEMORY
HOST ADDRESS (HEX)
000
001
002
003
004
005
006
..
3F8
3F9
3FA
3FB
3FC
3FD
3FE
3FF
NOTE: This memory map assumes a 4096 bit Serial EEPROM in PCMCIA mode.
ATTRIBUTE EEPROM ADDRESS
DATA
Data byte 0 Word 1 - Low Byte
Don't Care
Data byte 1 Word 1 - High Byte
Don't Care
Data byte 2 Word 2 - Low Byte
Don't Care
Data byte 3 Word 2 - High Byte
..
Data byte 1FC Word FE - Low Byte
Don't Care
Data byte 1FD Word FE- High Byte
Don't Care
Data byte 1FE Word FF - Low Byte
Don't Care
Data byte 1FF Word FF - High Byte
Don't Care
55
SMC91C95 SRAM
IN WORDS
..
IN BYTES
Byte 0
Byte1
Byte2
Byte3
..
Byte FC
Byte1FD
Byte1FE
Byte1FF
