SMC Networks SMC91C95 Product Manual page 51

I/O SPACE - BANK1
OFFSET
4 THROUGH 9 INDIVIDUAL ADDRESS
These registers are loaded starting at word
location 20h of the EEPROM upon hardware reset
or EEPROM reload in ISA mode only. The
registers can be modified by the software driver,
but a STORE operation will not modify (in ISA
mode only) the EEPROM Individual Address
contents.
In PCMCIA mode, the IEEE Individual Address is
stored in the EEPROM, but is stored in PCMCIA
Tuple format as defined in the Metaformat
specification. Refer to the PCMCIA v3.0 card
specification on the Metaformat.
HIGH
BYTE
0
LOW
BYTE
0
HIGH
BYTE
0
LOW
BYTE
0
HIGH
BYTE
0
LOW
BYTE
0
NAME
REGISTERS
ADDRESS 0
0 0 0
ADDRESS 1
0 0 0
ADDRESS 2
0 0 0
ADDRESS 3
0 0 0
ADDRESS 4
0 0 0
ADDRESS 5
0 0 0
51
TYPE
READ/WRITE
The SMC91C95 in PCMCIA mode knows nothing
about the location or structure of the IEEE Ethernet
Address stored in the EEPROM. Once this data is
stored in the CIS SRAM data buffer in the
SMC91C95, it is parsed by the host to extract the
IEEE Address information and stored manualy by
the LAN Driver.
Bit 0 of Individual Address 0 register corresponds
to the first bit of the address on the cable.
0 0
0 0
0 0
0 0
0 0
0 0
SYMBOL
IAR
0 0
0 0
0 0
0 0
0 0
0 0
