WOOSIM WSP-SM40 Operator's Manual

2inch mobile printer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WSP-SM40
MODEL
(2inch Mobile Printer)
Rev. 1.2
All specifications are subjected to change without notice
http://www.woosim.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WSP-SM40 and is the answer not in the manual?

Questions and answers

Related Manuals for WOOSIM WSP-SM40

Summary of Contents for WOOSIM WSP-SM40

  • Page 1 WSP-SM40 MODEL (2inch Mobile Printer) Rev. 1.2 All specifications are subjected to change without notice http://www.woosim.com...
  • Page 2 Copyright ⓒ2017 by Woosim Systems Inc. All rights reserved. The information contained in this manual is the property of Woosim Systems Inc. And may not be reproduced in whole or in part without the prior written permission of Woosim Systems Inc.  Trademark a registered trademark of Woosim Systems Inc.
  • Page 3 WSP-SM40 Rev. 1.2  Introduction The WSP-SM40 is the ideal solution for Mobile banking system , Retail, point of sales, Credit card Transaction, other traveling and mobile computing etc. The general features of WSP-SM40 printer are as follows: Pocket size (80.9×113.5×47.1mm) ...
  • Page 4 WSP-SM40 Rev. 1.2  Operating Precautions Please follow the precautions below to enjoy and maintain the full performance of the printer. Using the Printer  ● Be careful not to drop or bump the printer on a hard surface. ●...

  • Page 5: Table Of Contents

    WSP-SM40 Rev. 1.2 CONTENTS 1. Outline................................. 6 1.1. Model classifications..........................6 1.2 Product Part Number System ........................6 1.3. Specifications............................. 7 2. Setting up the printer............................9 2.1. Printer & Accessories ..........................9 2.2. Printer Features ............................10 2.3.

  • Page 6: Outline

    WSP-SM40 Rev. 1.2 WSP-SM40 Model Interface A1 : UART/Bluetooth Power None : DC 8.4V Model name Interface Spec. Wired Wireless RS-232C Bluetooth SC30 IrDA Wireless LAN RS-485 None Parallel None Example) 1. Porti-S40 Serial/Bluetooth Part No. ⇒ S40/A1 2. Porti-SC30 Bluetooth Only Part No. ⇒ SC30/Z1 Note) The above table is the interface format which is supported.

  • Page 7: Specifications

    WSP-SM40 Rev. 1.2 Item Specifications Print method Direct thermal line printing Characters per line 42cpl (MAX) Character size Eng: 9*24dots, 12*24dots Kor: 16*24dots, [24*24dots] Simplified/Traditional Chinese, Arabic, Cyrillic, Russian, Optional Characters Tukish, Greek, Japanese, Persian, Latin9 and Others upon request.
  • Page 8 WSP-SM40 Rev. 1.2 Item Specifications -10°C ~ 50°C (operating) Temperature -10°C ~ 70°C (storage) Environment conditions 30% - 80% (operating) Humidity 10% - 90% (storage) Mechanical 37,000,000 lines MCBF(Mean Cycle Between Failure) Head Approximately 50 Km < Table 1 >...

  • Page 9: Setting Up The Printer

    WSP-SM40 Rev. 1.2 & & Your printer box should include these items. If any items are damaged or missing, please contact your dealer for assistance. Communication cable Battery Pack WSP-SM40 Battery charger adaptor Thermal roll paper ▼ OPTIONAL External Battery Cradle...

  • Page 10: Printer Features

    WSP-SM40 Rev. 1.2 ▶ Part Name http://www.woosim.com...

  • Page 11: Dimensions

    WSP-SM40 Rev. 1.2 http://www.woosim.com...

  • Page 12: Replacing Paper Roll

    WSP-SM40 Rev. 1.2 Note : Be sure to use paper rolls that meet the specifications. Do not use paper rolls that have the paper glued to the core because the printer can not detect the paper end correctly. 1. Make sure that the printer is not receiving data; otherwise, data may be lost.

  • Page 13: Power Supply

    WSP-SM40 Rev. 1.2 The following specification is requested for Power supply. Battery Charger : DC 8.4V/0.8A Avoid using power supply which its power capacity of power current is extremely high. Warning : ● Before installing or removing the battery pack, ensure the printer is OFF.

  • Page 14: Recharging The Battery Pack

    WSP-SM40 Rev. 1.2 For recharging the battery pack, install the battery pack in the printer. Insert the Battery Charger or External Battery Cradle to the charge connector of the printer. NOTE : ● While charging the printer, turn off the printer power.

  • Page 15: Set Operation Mode

    WSP-SM40 Rev. 1.2 In keeping on pressing the Feed and Mode button simultaneously until after the ERROR lamp blinks 5 times, the printer comes out at the circumstance to change the printer mode. (refer Table 2) ** Only the printer which support iOS Bluetooth interface comes out at the circumstance to change the printer mode.
  • Page 16 WSP-SM40 Rev. 1.2 Change the mode and option using the mode Code.  MODE button : changing Printer OPTION status. (Error Lamp)  FEED button : changing MODE status. [Example] The defaults of the printer are : UART / 9600 bps / 8 data bit / No parity /1 stop bit / Density low /...
  • Page 17 WSP-SM40 Rev. 1.2 When you press FEED button once.   You will see present Quality mode in the LCD. (Low)  Press MODE Button once. And then the quality has set to Quality high. When you press FEED button once.

  • Page 18: Uart(Rs-232C Or Ttl)

    WSP-SM40 Rev. 1.2 Mode Option Mode No. Option No. (Feed Button) (Mode Button) UART Protocol UART Communication Bluetooth Port Protocol Bluetooth Bluetooth(iAP) 9600 bps 19200 bps Baud Rate 34800 bps 57600 bps 115200 bps 7 Data bit Data Bit 8 Data bit...

  • Page 19: Interface

    WSP-SM40 Rev. 1.2 The WSP-SM40 printer has a UART(RS-232C or TTL) interface and is connected by means of a 5 pin mini USB socket. In the following table, the signals present on the Mini- USB socket are listed: Pin No.

  • Page 20: Bluetooth

    WSP-SM40 Rev. 1.2 Category Specification Bluetooth Spec. Bluetooth Ver3.0 / Class2 (10m) Frequency band 2402~2480 MHz Protocol L2CAP, RFCOMM, SDP Profile GAP, SDAP, SPP & & ▶Please take notice that Magnetic Stripe Card should be swapped in direction of arrow.

  • Page 21: Smart Card Module

    WSP-SM40 Rev. 1.2 Contact Smart Card Reader Module for ISO/IEC-7816  Support Asynchronous Protocol T=0,T=1  Smart Card Connection  Short Circuit Current Limitation 6KV ESD Protection on whole Smart Card Interface Connector : Friction Type with Smart Card presence detection 2 SAM (Security Application Module) ...

  • Page 22: Communication Protocol Sequence

    WSP-SM40 Rev. 1.2 Host Command Module Execution Response 500ms timeout Host Command Command Command Module Command is Executio canceled Host Command Command Error Module CheckSumEr Executio http://www.woosim.com...

  • Page 23: Using The Printer

    WSP-SM40 Rev. 1.2  BUTTON - FEED Button : Use to feed paper continuously. - MODE Button : MODE Button is for use to change communication mode. (Refer to 2.6. Set operation mode for details about mode conversion)  LAMP - POWER lamp(GREEN) : Printer is ON and ready to receive data.

  • Page 24: The Self Test

    3. Printer will print out the current status. (F/W version and set contents) 4. And then pattern of characters will be printed out. 5. Self-test will be finished automatically and turned to the standby status. ※ In case printer does not work properly, please contact Woosim customer service center. http://www.woosim.com...

  • Page 25: Consumable Parts

    WSP-SM40 Rev. 1.2 Type : Thermal Paper Paper width : 57mm Paper thickness : 60±5 ㎛ Outer diameter : Ø40mm or less Recording side : Outside of roll Cautions 1. Do not paste the paper to the core. And the roll paper which has Near end mark printing on its near end is recommended.

  • Page 26: Revision History

    WSP-SM40 Rev. 1.2 Date Version Comments Jul. 25. 2014 Initialize Agency Approvals update p8, 12 Dimension update Jul. 01. 2016 p8, 24 SCR : EMV level 2 add Additional battery charging Notes Change page layout (B5→A4) May. 16. 2017 * Delete address...
