Body Solid S2LEC Assembly Instructions & Owner's Manual
  1. Manuals
  2. Brands
  3. Body Solid Manuals
  4. Fitness Equipment
  5. S2LEC
  6. Assembly instructions & owner's manual
Body Solid S2LEC Assembly Instructions & Owner's Manual

Body Solid S2LEC Assembly Instructions & Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
S2LEC
&
A s s e m b l y
I n s t r u c t i o n s
O W N E R ' S
M A N U A L
v. S2LEC-082816

Advertisement

loading

Related Manuals for Body Solid S2LEC

Summary of Contents for Body Solid S2LEC

  • Page 1 S2LEC & A s s e m b l y I n s t r u c t i o n s O W N E R ’ S M A N U A L v. S2LEC-082816...
  • Page 2 Replacement Owner’s Manuals and warning labels are available from your local Body-Solid dealer. If you have any questions about the operation, set up or maintenance of this machine please call our customer service department at 1 (800) 556-3113.

  • Page 3: Table Of Contents

    T a b l e o f C o n t e n t s • SAFETY INSTRUCTIONS......PAGE 4 • PREPARATION..........PAGE 5 • HARDWARE LIST........... PAGE 6 • HARDWARE ILLUSTRATION......PAGE 8 • PART / LIST ILLUSTRATION......PAGE 14 • ASSEMBLY INSTRUCTIONS......

  • Page 4: Safety Instructions

    Before beginning assembly, please take the time that we can assist you better. to read the instructions thoroughly. 1. Model Number m Read each step in the assembly instructions and 2. Place of Purchase follow the steps in sequence. Do not skip ahead. 3. Serial Number (S/N) If you skip ahead, you may learn later that you 4. Part # and Description have to disassemble components and that you may have damaged the equipment. m Assemble and operate the S2LEC on a solid, level surface. Locate the unit a few feet from the walls or furniture to provide easy access.

  • Page 5: Preparation

    P r e p a r a t i o n Thank you for purchasing the S2LEC. This machine is part of the Body-Solid line of quality strength training machines, which lets you target specific muscle groups to achieve better muscle tone and overall body conditioning. To maximize your use of the equipment please study this Owner’s Manual thoroughly. Required Tools Assembly Tips The basic tools that you must obtain before assembling Read all “Notes” on each page before beginning each the S2LEC include but are not limited to: step. While you may be able to assemble the S2LEC using the m Metric Allen Key Set illustrations only, important safety notes and other tips are included in the text.

  • Page 6: Hardware List

    S 2 L E C H a r d w a r e L i s t Part# Size Description Quantity M10X25mm FLAT HEAD CAP SCREW 4 PCS. M10X25mm FLAT HEAD CAP SCREW-NL 5 PCS. M10X100mm HEX HEAD BOLT 2 PCS. M10X105mm HEX HEAD BOLT 8 PCS.
  • Page 7 S 2 L E C H a r d w a r e L i s t Part# Size Description Quantity NYLON LOCK NUT 24 PCS. NYLON LOCK NUT 4 PCS. NYLON LOCK NUT 1 PCS. NYLON LOCK NUT 10 PCS. 1/2”-13 HEX NUT 1 PCS.

  • Page 8: Hardware Illustration

    S 2 L E C H a r d w a r e I l l u s t r a t i o n FLAT HEAD CAP SCREW M10X25mm Part #1 QTY. 4 (#1)FLAT HEAD CAP SCREW M10X25 FULL THREAD QTY.4 (#1)FLAT HEAD CAP SCREW M10X25 FULL THREAD QTY.4 FLAT HEAD CAP SCREW NYLON COATED Part #2 QTY.
  • Page 9 (#4)HEX HEAD BOLT M10X105 PARTIAL THREAD QTY.8 S 2 L E C H a r d w a r e I l l u s t r a t i o n (#5)HEX HEAD BOLT M10X30 PARTIAL THREAD QTY.2 HEX HEAD BOLT M10X35mm Part #7 QTY.
  • Page 10 (#9)HEX HEAD BOLT M12X35 PARTIAL THREAD QTY.4 (#9)HEX HEAD BOLT M12X35 PARTIAL THREAD QTY.4 Part #11 SOCKET HEAD BOLT M8*20 FULL 3PCS. Part #11 SOCKET HEAD BOLT M8*20 FULL 3PCS. S 2 L E C H a r d w a r e I l l u s t r a t i o n Part #11 SOCKET HEAD BOLT M8*20 FULL 3PCS.
  • Page 11 S 2 L E C H a r d w a r e I l l u s t r a t i o n SET SCREW 10-32X1/8” Part #19 QTY. 10 Part #16 ALLEN SCREW 10-32X3.2mm FULL QTY. 8 Part #16 ALLEN SCREW 10-32X3.2mm FULL QTY.
  • Page 12 NUT M12 Part #42 NYLON LOCK NUT M12 QTY. 14 QTY. 14 S 2 L E C H a r d w a r e I l l u s t r a t i o n PART #41 NYLON LOCK NUT M12 QTY.4 (#40)NYLON LOCK NUT M10 QTY.23 (#54)FLAT WASHER 9X 16X1.6 QTY.8...
  • Page 13 (#50)SPRING WASHER 10 QTY.6 (#43)NYLON LOCK NUT M8 QTY.4 (#50)SPRING WASHER 10 QTY.6 S 2 L E C H a r d w a r e I l l u s t r a t i o n (#43)NYLON LOCK NUT M8 QTY.4 (#50)SPRING WASHER 10 QTY.6 FLAT WASHER Part #51...

  • Page 14: Part / List Illustration

    S 2 L E C P a r t s L i s t / I l l u s t r a t i o n PART F ADJUSTMENT CAM, 1PCS...
  • Page 15 S 2 L E C P a r t s L i s t / I l l u s t r a t i o n PART N FRAME N, 1PCS 1162.7X286.6X2 PART Q LEG HOLD DOWN, 1PCS 1212.7X286.6X2 PART L ANKLE ADJUSTER, 1PCS PART P LEVER, 1PCS...
  • Page 16 S 2 L E C P a r t s L i s t / I l l u s t r a t i o n 1162.7X286.6X2 1212.7X286.6X2...
  • Page 17 S 2 L E C P a r t s L i s t / I l l u s t r a t i o n SELECTOR ROD TOP BOLT, ø 1PCS 25.4X310mm CYLINDER CABLE LOCK , ROLLER END CAP, 2PCS 1PCS POP PIN A, 1PCS PLASTIC COVER...
  • Page 18 S 2 L E C P a r t s L i s t / I l l u s t r a t i o n 5 PCS BEARING , 4PCS 4 PCS...
  • Page 19 S 2 L E C P a r t s L i s t / I l l u s t r a t i o n 50mmX50mm 4 PCS 25mmX76mm 2 PCS 50mmX76mm 4 PCS ø ø 25.4X 32X18mm...
  • Page 20 6 PCS PART #93 POP PIN B, 1PCS BIG PULLEY, 6 PCS 3590mm NYLON CAP, 1 PCS PART #94 CHROME ADJUSTMENT PLATE, 1PCS PART #95 BUSHING,4 PCS ø ø 25.4X 32X7.5mm...
  • Page 21 S 2 L E C P a r t s L i s t / I l l u s t r a t i o n PART #96 SHORT RUBBER SLEEVE, PART #100 LEVER GRIP, 1 PCS 2 PCS PART #97 LONG RUBBER SLEEVE, PART #101...
  • Page 22 S 2 L E C P a r t s L i s t / I l l u s t r a t i o n PART #107 LEVER,1 PCS PART #104 STEEL PLATE, 2 PCS PART #105 POP PIN C,1 PCS PART #108 SPRING,1 PCS PART #106...
  • Page 23 N o t e...

  • Page 24: Assembly Instructions

    S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware in this step. DO NOT wrench tighten unless instructed. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
  • Page 25 S T E P STEP1 Above shows Step 1 assembled and completed. 51 40 51 40 40 51...
  • Page 26 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Wrench tighten ALL hardware at the end of STEP 2A. Some components may be pre-as- sembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
  • Page 27 S T E P STEP2 Above shows Step 2 assembled and completed.
  • Page 28 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware first in this step. Wrench tighten ALL hardware at the end of STEP 3E. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
  • Page 29 S T E P STEP3 Above shows Step 3 assembled and completed.                                   ...
  • Page 30 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware first in this step. Wrench tighten ALL hardware at the end of STEP 4H. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
  • Page 31 S T E P Above shows Step 4 assembled and completed. STEP4...
  • Page 32 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware first in this step. Wrench tighten ALL hardware at the end of STEP 5D. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
  • Page 33 S T E P STEP5 Above shows Step 5 assembled and completed. 7 12 89 51 8 51...
  • Page 34 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Wrench tighten ALL hardware at the end of Each Step. Some components may be pre-as- sembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
  • Page 35 S T E P STEP6 Above shows Step 6 assembled and completed.
  • Page 36 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware first in this step. Wrench tighten ALL hardware at the end of STEP 7B. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
  • Page 37 S T E P STEP7 Above shows Step 7 assembled and completed.
  • Page 38 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on. 7A. Attach Seat Plate (J) to Frame A (A) using: 4 - (#1) M10X25mm Flat Head Cap Screw 4 - (#51) M10 Flat Washer...
  • Page 39 S T E P STEP8 Above shows Step 8 assembled and completed.
  • Page 40 N o t e s PCL Badge Location...

  • Page 41: Exploded View

    S 2 L E C E x p l o d e d V i e w...

  • Page 42: Contact Page

    Copyright 2009. Body-Solid. All rights reserved. Body-Solid reserves the right to change design and specifications when we feel it will improve the product. Body-Solid machines maintain several patented and patent pending features and designs. All rights reserved on all design patents and utility patents.
