- Page 1 SVKR1000 & A s s e m b l y I n s t r u c t i o n s O W N E R ’ S M A N U A L V. SVKR1000-081915...
- Page 2 W a r n i n g , S a f e t y & M a i n t e n a n c e Be sure that all users carefully read and understand all warning, safety and maintenance labels on the machine before each use.
-
Page 3: Table Of Contents
T a b l e o f C o n t e n t s • SAFETY INSTRUCTIONS......PAGE 4 • PREPARATION..........PAGE 5 • HARDWARE LIST........... PAGE 6 • PARTS LIST............ PAGE 7 • HARDWARE ILLUSTRATION......PAGE 8 • ASSEMBLY INSTRUCTIONS......PAGE 12 • EXPLODED VIEW......... -
Page 4: Safety Instructions
Before beginning assembly, please take the time to read the instructions thoroughly. 1. Model Number 2. Place of Purchase m Read each step in the assembly instructions and 3. Serial Number (S/N) follow the steps in sequence. Do not skip ahead. 4. Part # and Description If you skip ahead, you may learn later that you have to disassemble components and that you may have damaged the equipment. m Assemble and operate the SVKR1000 on a solid, level surface. Locate the unit a few feet from the walls or furniture to provide easy access. -
Page 5: Preparation
P r e p a r a t i o n Thank you for purchasing the SVKR1000. This bench is part of the Body-Solid line of quality strength training machines, which lets you target specific muscle groups to achieve better muscle tone and overall body conditioning. To maximize your use of the equipment please study this Owner’s Manual thoroughly. Required Tools Assembly Tips The basic tools that you must obtain before assembling Read all “Notes” on each page before beginning each the SVKR1000 include but are not limited to: step. While you may be able to assemble the SVKR1000 using m Metric Allen Key Set the illustrations only, important safety notes and other tips are included in the text. -
Page 6: Hardware List
S V K R 1 0 0 0 H a r d w a r e L i s t Part# Size Description Quantity M12X130mm HEX HEAD BOLT 20 PCS. M12X80mm HEX HEAD BOLT 4 PCS. M12X30mm SOCKET HEAD CAP SCREW 4 PCS. -
Page 7: Parts List
S V K R 1 0 0 0 P a r t s L i s t Part# Description Quantity BASE FRAME 2 PCS. LOWER UPRIGHT 2 PCS. BASE PLATE 1 PCS. CENTER FRAME 1 PCS. UPPER LEFT UPRIGHT 1 PCS. UPPER RIGHT UPRIGHT 1 PCS. -
Page 8: Hardware Illustration
S V K R 1 0 0 0 H a r d w a r e I l l u s t r a t i o n Part #1 HEX HEAD BOLT M12x130mm QTY. 20... - Page 9 S V K R 1 0 0 0 H a r d w a r e I l l u s t r a t i o n Part #6 SOCKET HEAD CAP SCREW M10x20mm QTY. 4...
- Page 10 S V K R 1 0 0 0 H a r d w a r e I l l u s t r a t i o n Part #11 LOCK WASHER M12 QTY. 4...
- Page 11 N o t e...
-
Page 12: Assembly Instructions
S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware in this step. DO NOT wrench tighten unless instructed. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on. - Page 13 S T E P Above shows Step 1 assembled and completed.
- Page 14 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware first in this step. Wrench tighten ALL hardware at the end of and after STEP 2C. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
- Page 15 S T E P Above shows Step 2 assembled and completed. Figure # 1...
- Page 16 S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Wrench tighten ALL hardware at the end of each step. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
- Page 17 S T E P Above shows Step 3 assembled and completed.
-
Page 18: Exploded View
S V K R 1 0 0 0 E x p l o d e d V i e w... - Page 19 N o t e s...
-
Page 20: Contact Page
PLEASE WRITE YOUR SERIAL NUMBER IN THE BOXES BELOW 010192-��-��-����-���� S/N # 1900 S. Des Plaines Ave. Forest Park, Il 60130 Phone:(708)427-3555 Fax:(708)427-3556 Hours: M-F 8:30 - 5:00 CST www.bodysolid.com Copyright 2009. Body-Solid. All rights reserved. Body-Solid reserves the right to change design and specifications when we feel it will improve the product. Body-Solid machines maintain several patented and patent pending features and designs.
