TrueAlert ES Operation Advantage (Cont'd)
Reducing Installation and Testing Time. With
separate controls on the same two-wire SLC, installation
time and expense for both retrofit and new construction can
be significantly reduced. When Class B wiring is used,
wiring can be "T" tapped, allowing more savings in
distance, wire, conduit (size and utilization), and overall
installation efficiency. Use of Self-Test and Magnet Test
features improves installation efficiency. TrueAlert device
reports conveniently identify information about each
connected appliance.
TrueAlert ES Diagnostics
IDNAC SLCs are in
Test Features. When
mode, Self-Test and Magnet Test features provide individual
appliance testing. With the Self-Test feature, appliance
operation can be confirmed without leaving the control panel.
Additionally, each appliance's LED can be selected to pulse
when it receives a supervision poll during normal operation.
Self-Test Details. Selecting Self-Test Mode from the control
panel allows on-board sensors, depending on the device type,
to detect its own strobe and/or horn output and then report their
status to the control panel.
Product Selection
TrueAlert ES Wall Mount Addressable Strobes
TrueAlert ES addressable VO (strobe) appliances include cover and matching mounting plate except as noted;
Dimensions with Cover = 5 ⅛" H x 5" W x 1 ½" D (130 mm x 127 mm x 38 mm)
Model*
Cover Color
49VO-WRF(-BA)
Red
49VO-WWF(-BA)
White
49VO-WRA(-BA)
Red
49VO-WWA(-BA)
White
49VO-APPLW
Select cover and mounting plate separately
Separate Mounting Plate
Model
Color
49MP-AVVOWR
Red
49MP-AVVOWW
White
(Required when ordering model 49VO-APPLW)
Separate Covers
Model*
49VOC-WRFIRE
49VOC-WWFIRE
49VOC-WRALT
49VOC-WWALT
49VOC-WRS
* Note: (-BA) indicates model is available either with or without the -BA suffix. Model numbers ending in -BA, APPLW models, and
separate mounting plates are assembled in the USA.
Mounting Adapters and Wire Guard
Model
Color
Description
4905-9937
Red
Surface Mount Adapter Skirt
4905-9940
White
Red Adapter Plate for mounting to Simplex 2975-9145 Box
4905-9931
(typically for retrofit, mount vertical or horizontal)
2975-9145 Red Mounting Box, requires 4905-9931 Adapter Plate
Red wire guard with mounting plate, compatible with semi-
4905-9961
flush or surface mount boxes
diagnostic
Wording
Lens Color
FIRE
Clear
ALERT
Note
Mounting Plate is required when ordering model 49VO-APPLW
Color
Wording
Red
FIRE
White
Red
ALERT
White
Red
Blank
TrueAlert ES Diagnostics (Continued)
Self-Test Details (Continued). Operation is by selected
VNAC appliance groups and is either automatic (all briefly
simultaneously activated) or individually activated by applying
a magnet. (Refer to data sheet S4100-0100 for more Self-Test
information.)
Silent Appliance Magnet Test. In this test mode, in
response to application of a magnet, the appliance LED
pulses sequentially to conveniently indicate the appliance's
address.
Operational Appliance Magnet Test. In this test mode,
after the address is indicated by pulsing the appliance LED,
the strobe will briefly flash to indicate proper operation.
TrueStart Instrument Two (TSIT). The 2nd generation
of the Simplex TrueStart Test Instrument adds testing of
IDNAC SLC wiring and TrueAlert ES appliances to its
ability to test IDCs, NACs, and IDNet communications
before connection to the control panel. Please contact your
local Simplex representative for additional information.
TrueAlert Addressable Wiring Isolator
Isolator Model 4905-9929 is available for remote
mounting on TrueAlert addressable circuits to isolate short
circuited wiring from functioning wiring. (See data sheet
S4905-0001.)
Model*
Cover Color
49VO-WRQ
Red
49VO-WWQ
White
49VO-WRS(-BA)
Red
49VO-WWS(-BA)
White
Model*
49VOC-WRFEU
49VOC-WWFEU
49VOC-WRBLNG
49VOC-WWBLNG
49VOC-WWS
Dimensions
5 ⅜" H x 5 ¼" W x 1 ⅝" D (136 mm x 133 mm x 41 mm)
Total depth with strobe = 4 ⅜" (111 mm)
5
8
⁄
" x 5 ¾" x 0.060" Thick (211 mm x 146 mm x 1.5 mm)
16
7 ⅞" x 5 ⅛" x 2 ¾" D (200 mm x 130 mm x 70 mm)
1
1
6
⁄
" H x 6
⁄
" W x 3 ⅛" D (154 mm x 154 mm x 79 mm)
16
16
2
Wording
Lens Color
FEU
Clear
Blank
Color
Wording
Red
FEU
White
Red
FEU/FIRE
White
White
Blank
S49VO-0001-3 8/2014
