Table 24 - Printhead PF-05 Specifications
Model
Type
Head configuration
Nozzle pitch
Nozzle per chip
Droplet size
Head replacement
imagePROGRAF iPF8400SE Service Guide
imagePROGRAF iPF8400SE Service Guide
Printhead PF-05
PF-05
Bubble-jet on demand
6 colors integrated type (6 chips per print head)
1,200 dpi x 2
MBK/BK/M/Y: 2,560 nozzles for each color
C/PC/PM/GY: 5,120 nozzles for each color
4 picoliters per color
User replacement
February 2014
Page 36
