SECTION 1
General
● Frequency range
Receive Operable range
Guaranteed range
Transmit
( The transmit frequency range will differ,
depending on the transceiver version.)
● Operating mode
● Number of memory channels
● Antenna impedance
● Power supply voltage
● Polarity
● Power consumption
Stand-by
Maximum audio
Transmit (at 100 W)
● Operable temperature range
● Frequency stability
● Frequency resolution
● Dimensions
(projections not included)
● Weight
Transmitter
● Output power
CW, RTTY, PSK, FM
AM
● Modulation method
SSB
FM
AM
● Spurious emission
Harmonics 1.8 MHz~28 MHz
50 MHz band
Out-of-band 1.8 MHz~28 MHz
emission
50 MHz band
● Carrier suppression
● Unwanted sideband suppression
● Microphone impedance
● ∂TX variable range

SPECIFICATIONS

0.030000 MHz ~ 60.000000MHz
0.500000 MHz ~ 29.999999 MHz
50.000000 MHz ~ 54.000000 MHz
0.135700 MHz ~ 0.137800 MHz (EUR only)
1.800000 MHz 1.999999 MHz
3.500000 MHz ~ 3.999999 MHz
5.332000 MHz, 5.348000 MHz, 5.358500 MHz, 5.373000 MHz,
5.405000 MHz (USA only)
7.000000 MHz ~ 7.300000 MHz
10.100000 MHz ~ 10.150000 MHz
14.000000 MHz ~ 14.350000 MHz
18.068000 MHz ~ 18.168000 MHz
21.000000 MHz ~ 21.450000 MHz
24.890000 MHz ~ 24.990000 MHz
28.000000 MHz ~ 29.700000 MHz
50.000000 MHz ~ 54.000000 MHz
USB, LSB, CW, RTTY, PSK, AM, FM
101 (99 regular + 2 scan edges)
50 Ω (nominal: at antenna tuner OFF)
13.8 V DC ±15%
Negative ground
3.0 A
3.5 A
23.0 A
0°C~50°C (32°F~122°F)
±0.5 ppm (0°C~50°C)
Minimum 1 Hz
340(W)×118(H)×277(D) mm (13.4(W)×4.6(H)×10.9(D) inches)
Approximately 8.5 kg (18.7 lb)
1 W~100 W
1 W~25 W
Digital PSN modulation
Digital Reactance modulation
Digital Low Power modulation
Less than –50 dB
Less than –63 dB
Less than –40 dB
Less than –60 dB
More than 50 dB
More than 50 dB
600 Ω
±9.999 kHz
1-1
