Icom IC-7610 Service Manual page 52

[BPF-B UNIT]
REF PART
NO. NO.
C1208 4030023720 S.CER 0603N470J500CT
C1209 4030023400 S.CER 0603N8R0D500CT
C1210 4030023580 S.CER 0603N220J500CT
C1211 4030023500 S.CER 0603N150J500CT
C1212 4030023720 S.CER 0603N470J500CT
C1213 4030023520 S.CER 0603N180J500CT
C1214 4030023530 S.CER 0603N181J500CT
C1215 4030023720 S.CER 0603N470J500CT
C1216 4030023870 S.CER 0603B104K500CT
C1301 4030023490 S.CER 0603N121J500CT
C1302 4030023520 S.CER 0603N180J500CT
C1303 4030023870 S.CER 0603B104K500CT
C1304 4030023670 S.CER 0603N330J500CT
C1305 4030023520 S.CER 0603N180J500CT
C1306 4030023450 S.CER 0603N100D500CT
C1307 4030023670 S.CER 0603N330J500CT
C1308 4030023720 S.CER 0603N470J500CT
C1309 4030023450 S.CER 0603N100D500CT
C1310 4030023670 S.CER 0603N330J500CT
C1311 4030023450 S.CER 0603N100D500CT
C1312 4030023670 S.CER 0603N330J500CT
C1313 4030023520 S.CER 0603N180J500CT
C1314 4030023490 S.CER 0603N121J500CT
C1315 4030023520 S.CER 0603N180J500CT
C1316 4030023870 S.CER 0603B104K500CT
C1401 4030023460 S.CER 0603N101J500CT
C1403 4030023870 S.CER 0603B104K500CT
C1404 4030023580 S.CER 0603N220J500CT
C1405 4030023480 S.CER 0603N120J500CT
C1406 4030023480 S.CER 0603N120J500CT
C1407 4030023580 S.CER 0603N220J500CT
C1408 4030023580 S.CER 0603N220J500CT
C1409 4030023390 S.CER 0603N7R0D500CT
C1410 4030023580 S.CER 0603N220J500CT
C1411 4030023480 S.CER 0603N120J500CT
C1412 4030023580 S.CER 0603N220J500CT
C1413 4030023480 S.CER 0603N120J500CT
C1414 4030023460 S.CER 0603N101J500CT
C1416 4030023870 S.CER 0603B104K500CT
C1501 4030023460 S.CER 0603N101J500CT
C1502 4030023730 S.CER 0603N471J500CT
C1503 4030023870 S.CER 0603B104K500CT
C1504 4030023510 S.CER 0603N151J500CT
C1505 4030023750 S.CER 0603N560J500CT
C1506 4030023720 S.CER 0603N470J500CT
C1507 4030023790 S.CER 0603N820J500CT
C1508 4030023520 S.CER 0603N180J500CT
C1509 4030023760 S.CER 0603N680J500CT
C1510 4030023870 S.CER 0603B104K500CT
J1001 6510030150 S.CON 40RF-JMCS-G-1B-TF
(N) (LF) (SN)
J1002 6510030220 S.CON 50RF-JMCS-G-1B-TF
(N) (LF) (SN)
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
B
B
H/V
33.5/13.5
32.2/13.5
37.5/16.3
37.5/17.5
38.5/14.0
39.8/14.0
41.8/14.3
43.0/14.3
48.8/14.3
19.5/47.8
20.8/47.8
15.8/47.0
27.0/47.8
28.3/47.8
32.0/51.0
32.0/49.8
30.0/46.8
31.3/46.8
35.0/51.0
35.0/49.8
36.3/47.8
37.5/47.8
39.5/47.8
40.8/47.8
47.8/46.3
20.5/30.5
17.3/28.8
27.3/30.0
28.5/30.0
31.5/32.3
31.5/33.5
30.5/29.5
31.8/29.5
34.5/33.5
34.5/32.3
36.5/29.5
37.8/29.5
40.7/30.5
44.5/28.0
25.2/24.2
27.5/22.1
20.5/24.0
27.5/20.9
30.5/24.6
32.7/23.8
32.7/25.0
34.8/22.3
34.8/25.1
41.6/20.9
50.0/27.3
10.0/27.3
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION= See the BOARD LAYOUTS for details
5-34
