Icom IC-7610 Service Manual page 54

[RF UNIT]
REF PART
NO. NO.
J1001* 6510028210 SJ050010 (TMP-J01X-V6)
J1002* 6510028210 SJ050010 (TMP-J01X-V6)
J1071* 6510028210 SJ050010 (TMP-J01X-V6)
J1072* 6510028210 SJ050010 (TMP-J01X-V6)
J1091* 6510028210 SJ050010 (TMP-J01X-V6)
J1101* 6510028210 SJ050010 (TMP-J01X-V6)
J1102* 6510028210 SJ050010 (TMP-J01X-V6)
J1171* 6510028210 SJ050010 (TMP-J01X-V6)
J1172* 6510028210 SJ050010 (TMP-J01X-V6)
J1191* 6510028210 SJ050010 (TMP-J01X-V6)
J1301* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
J1401* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
J2001* 6510032230 40P9.0-JMCS-G-B-TF (N)
J2002* 6510032240 50P9.0-JMCS-G-B-TF (N)
J2481* 6510028210 SJ050010 (TMP-J01X-V6)
J3001* 6510032230 40P9.0-JMCS-G-B-TF (N)
J3002* 6510032240 50P9.0-JMCS-G-B-TF (N)
J3481* 6510028210 SJ050010 (TMP-J01X-V6)
J4001* 6450002520 RL-1515-2 (B.B)-L
J4002* 6510023730 LGY6502-0600C
J4003* 6510023730 LGY6502-0600C
J4004* 6510031660 LGR4609-7100F
J4005* 6510023730 LGY6502-0600C
J4006* 6510023671 TCS4480-0141577
J4007* 6510023661 TCS4470-0141577
J4051* 6510028210 SJ050010 (TMP-J01X-V6)
[DIGISEL-A UNIT]
REF PART
NO. NO.
J1* 6510028210 SJ050010 (TMP-J01X-V6)
J2* 6510028210 SJ050010 (TMP-J01X-V6)
J2017* 6510019971 52808-1071
J2018* 6510003391 B3B-EH-S (LF) (SN)
MP1* 8930062740 2590 M-SPRING
MP2* 8930062740 2590 M-SPRING
MP3* 8930062740 2590 M-SPRING
MP4* 8930062740 2590 M-SPRING
MP5* 8930062740 2590 M-SPRING
MP8 8510018460 3009 DIGISEL CASE
MP9 8510018470 3009 DIGISEL COVER
MP14 8810007231 SET SCREWH M3×8 ZC3
MP15 8810007231 SET SCREWH M3×8 ZC3
[DIGISEL-B UNIT]
REF PART
NO. NO.
J1* 6510028210 SJ050010 (TMP-J01X-V6)
J2* 6510028210 SJ050010 (TMP-J01X-V6)
J2017* 6510019971 52808-1071
J2018 6510003391 B3B-EH-S (LF) (SN)
MP1* 8930062740 2590 M-SPRING
MP2* 8930062740 2590 M-SPRING
MP3* 8930062740 2590 M-SPRING
MP4* 8930062740 2590 M-SPRING
MP5* 8930062740 2590 M-SPRING
MP8 8510018460 3009 DIGISEL CASE
MP9 8510018470 3009 DIGISEL COVER
MP14 8810007231 SET SCREWH M3×8 ZC3
MP15 8810007231 SET SCREWH M3×8 ZC3
*: Refer to "BOARD LAYOUTS" for the location.
**: Refer to "GENERAL WIRING" for the connection
Screw abbreviations
DESCRIPTION
DESCRIPTION
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head NI: Nickel ZU: Zinc SUS: Stainless
[PA UNIT]
REF PART
QTY.
NO. NO.
1 J101* 6510028210 SJ050010 (TMP-J01X-V6)
1 J591* 6510018971 B4B-PH-SM4-TB (LF) (SN)
1 J701* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
1 J721* 6510022311 B5B-PH-SM4-TB (LF) (SN)
1 J941 6510028210 SJ050010 (TMP-J01X-V6)
1
1
1 F431* 5220000400 FHA010-01F
1 F432 5210000940 1205
1
1
1 W1* 8900017860 OPC-1857
1
1
1 MP301 8930075440 3015 RUG SPRING
1 MP302 8930075440 3015 RUG SPRING
1
1
1
1
1
1
[TUNER UNIT]
1
1
1
REF PART
1
NO. NO.
W2001* 8970024721 1.5DCOAXIAL140MM-1 C31/C31
J1001* 6510028210 SJ050010 (TMP-J01X-V6)
J1002* 6510028210 SJ050010 (TMP-J01X-V6)
J1003* 6510028210 SJ050010 (TMP-J01X-V6)
J1801* 6510021722 30FLT-SM2-TB (LF) (SN) (M)
J2001* 6510028210 SJ050010 (TMP-J01X-V6)
QTY.
J2002* 6510028210 SJ050010 (TMP-J01X-V6)
J2003* 6510028210 SJ050010 (TMP-J01X-V6)
1
1
1
MP1301* 8510013390 2355 MIX CASE
1
MP2001* 8930094090 3768 ANT SPRING
MP2002* 8930094090 3768 ANT SPRING
1
1
1
1
1
[FRONT UNIT]
1
1
7
REF PART
6
NO. NO.
DS1 5030004250 LVCG9ZA04YS
W11** 8600037640 SX3864 P11*P12FR (3864-4)
W21** 8900009231 OPC-908A (P1N10L60)
W22** 8900009231 OPC-908A (P1N10L60)
W23** 8900009231 OPC-908A (P1N10L60)
W24** 8900009231 OPC-908A (P1N10L60)
QTY.
EP1 0880002780 EX-3210 #01
1
EP2 6910022560 SNAP PLATE
1
EP3 6910022560 SNAP PLATE
1
EP10 0880004510 EX-3956 #11
1
MP1 8210032661 3864 FRONT PANEL -1
1
MP20 8610016280 KNOB K-311 ASSEMBLY
1
MP21 8610016300 KNOB K-312 ASSEMBLY
1
MP22 8610016310 KNOB K-313 ASSEMBLY
1
MP23 8610016020 KNOB K-314
1
MP24 8610016030 KNOB K-315
1
MP25 8610016040 KNOB K-316
1
MP26 8610016050 KNOB K-317
7
MP27 8610016060 KNOB K-318
6
MP28 8610016070 KNOB K-319
MP29 8610016080 KNOB K-320
MP30 8610016090 KNOB K-321
MP40 8610016321 KNOB N-447 ASSEMBLY-1
MP41 8110011190 KNOB N-447 COVER (TOP)
MP42 8930095990 3864 BRAKE BUTTON
MP45 8930098800 HIMELON SHEET (EC)
MP50 8610016100 KNOB N-441
MP51 8610016180 KNOB N-442
MP52 8610016190 KNOB N-443
MP53 8610016200 KNOB N-444
MP54 8610016210 KNOB N-445
MP55 8610016350 KNOB N-446 ASSEMBLY
MP60 8010024090 3864 SUB CHASSIS ASSEMBLY
MP62 8930096770 3864 LCD SPONGE
MP63 8930080340 DOUBLE SIDE TAPE (BH)
MP70 8310064660 2590 NAME PLATE (A) (SILVER)
MP80 8930077360 3073 BRAKE PAD
MP81 8930094550 3765 BRAKE SHEET
MP83 8810003560 M4×6 SUS
MP100 8810008631 PHBT M3×6 NI-ZC3
MP101 8810008761 PHBT M2×8 NI-ZC3
6-2
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
19
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
3
3
3
1
1
1
1
1
1
1
1
2
1
1
2
