Icom IC-7610 Service Manual page 7

• MAIN/DIGISEL-A/DIGISEL-B (TOP VIEW)
D _ S CTRL
(IC4)
J2017
D _ S CTRL
(IC5)
J2
J2018
J451
J602
J611
J361
SHIFT REGISTER
(IC411)
MULTI PLEXER
(IC501)
J8001
J101
J8501
J8502
J301
DIGISEL-A UNIT
J1
MAIN UNIT
SD RAM
(IC5101)
DIGISEL-B UNIT
D _ S CTRL
J2 (IC5)
J251 J341
J201 J2001
SD RAM AF AMP
(IC5151) (IC3031)
COMM FPGA
(IC5001)
SUB CPU
(IC6001)
2-2
J2017
D _ S CTRL
(IC4)
J2018
J1
J601
J621
J151
J321
MAIN CPU
(IC4001)
J7401 [LAN]
J351
LVDS XMITER
(IC6301)
J6201 [EXT-DISP]
DVI XMITER
(IC6201)
J9401 [USB-2]
USB 3.0 I/F
(IC9401)
J7121 [USB-1]
J3071
J3051 [EXT-SP(B)]
J3061 [EXT-SP(A)]
J331
USB HUB
(IC7101)
USB CODEC
(IC7031)
