Icom IC-PCR100 Service Manual page 30

SECTION SECTION 7
7-1 CABINET PARTS
[CHASSIS]
REF ORDER
NO. NO.
J 1 6510015550 Connector BNC-R117 (incl. nut)
MP 1 8110006550 2197 Cover
MP 2 8010017560 2197 Chassis
MP 3 8510011930 2197 Shield U-plate
MP 4 8510011910 2197 Shield L-plate
MP 6 8930039620 Leg cushion (A)
MP 7 8930011900 SP net (A)
Screw PH B0 3 × 8 NI-ZU
MP 9 8810008660
Set screw (H) M3 × 8
MP10 8810007230
MP12 8850001560 Star washer M4
MP13 8850000140 Flat washer M4 NI BS
Hexagon bolt M4 × 8 NI
MP14 8810009880
MP24 8930041500 1887 Lenz
MP27 8930048610 2197 A-Sponge
MP29 8930048440 2197 Plate
MP30 8930048400 2197 Sponge
MP31 8930048390 Himeron seat (BZ)
MP32 8930048900 Rubber sheet
SP 1 2510000960 Speaker
[MAIN UNIT]
REF ORDER
NO. NO.
MP 1 8510006941 DTMF Shield case-1
MP 2 8930044920 2032 Coil cover
MP 3 8510004190 443 Prescaler shield case
MP 4 8510011921 2197 Shild case-1
MP 6 8930014140 Grounding spring (D)
MP 7 8930045920 2056 Sponge
Screw abbreviations: PH: Pan head B0: Tapping screw
NI: Nickel ZK: Black
MECHANICAL PARTS AND DISASSEMBLY PARTS LIST
DESCRIPTION QTY.
DESCRIPTION QTY.
7-2 ACCESSORIES
REF ORDER
NO. NO.
1 F1 5210000040
W1 8900007650
1
1 W2 8900001410
1
1 EP1 3310002187
4 EP2
EP3 Optional product AC adaptor BC-123A [USA-1] [CAN]
1
4
7
1
1
1
1
1
1
1
EP1
3
1
1
W1
1
1
1
1
1
1
7 - 1
DESCRIPTION
Fuse FGB 2A [UK] only
RS-232C cable OPC-743
DC cable OPC-131 [UK] only
2197 Antenna
3.5" FD 40MF2HDGEDV
AC adaptor BC-123E [EUR] [OTH]
EP2
EP3
F1
W2
QTY.
2
1
1
1
1set
1
1
