[MAIN UNIT]
REF ORDER
NO. NO.
L154 6200005680 S.COIL
L155 6200005680 S.COIL
L156 6200005690 S.COIL
L157 6200005690 S.COIL
L158 6200005720 S.COIL
L160 6200005700 S.COIL
L161 6200001620 S.COIL
L162 6200002240 S.COIL
L163 6200005690 S.COIL
L167 6200006980 S.COIL
L168 6200006980 S.COIL
L169 6200005500 S.COIL
L170 6200005500 S.COIL
L171 6200005500 S.COIL
L172 6200002520 S.COIL
L173 6200005620 S.COIL
L174 6200005600 S.COIL
L176 6200005630 S.COIL
L177 6200002890 S.COIL
L178 6200005630 S.COIL
L179 6200005500 S.COIL
L180 6200005700 S.COIL
L181 6200005700 S.COIL
R1 7030000330 S.RESISTOR
R2 7030003440 S.RESISTOR
R3 7030000230 S.RESISTOR
R5 7030003560 S.RESISTOR
R6 7030003440 S.RESISTOR
R8 7030003440 S.RESISTOR
R9 7030000020 S.RESISTOR
R14 7030003480 S.RESISTOR
R15 7030003480 S.RESISTOR
R17 7030003480 S.RESISTOR
R19 7030003480 S.RESISTOR
R20 7030003640 S.RESISTOR
R22 7030003640 S.RESISTOR
R23 7030003640 S.RESISTOR
R24 7030003760 S.RESISTOR
R26 7030003290 S.RESISTOR
R28 7030003280 S.RESISTOR
R29 7030003640 S.RESISTOR
R30 7030003440 S.RESISTOR
R33 7030003640 S.RESISTOR
R34 7030003760 S.RESISTOR
R35 7030003480 S.RESISTOR
R36 7030003290 S.RESISTOR
R38 7030003280 S.RESISTOR
R39 7030003640 S.RESISTOR
R43 7030003640 S.RESISTOR
R44 7030003760 S.RESISTOR
R45 7030003290 S.RESISTOR
R47 7030003280 S.RESISTOR
R48 7030004050 S.RESISTOR
R49 7030003640 S.RESISTOR
R50 7030003480 S.RESISTOR
R53 7030003640 S.RESISTOR
R54 7030003760 S.RESISTOR
R55 7030003290 S.RESISTOR
R57 7030003280 S.RESISTOR
R59 7030003640 S.RESISTOR
R72 7030003310 S.RESISTOR
R73 7030004050 S.RESISTOR
R74 7030007680 S.RESISTOR
R75 7030003480 S.RESISTOR
R76 7030003200 S.RESISTOR
R77 7030003320 S.RESISTOR
R79 7030003680 S.RESISTOR
R80 7030003610 S.RESISTOR
R81 7030003400 S.RESISTOR
R82 7030003420 S.RESISTOR
R83 7030003520 S.RESISTOR
R84 7030003200 S.RESISTOR
R87 7030003320 S.RESISTOR
R88 7030003440 S.RESISTOR
R89 7030003460 S.RESISTOR
R90 7030003440 S.RESISTOR
R92 7030003440 S.RESISTOR
R93 7030003230 S.RESISTOR
R94 7030003370 S.RESISTOR
R95 7030003370 S.RESISTOR
DESCRIPTION
ELJRE 15NG-F
ELJRE 15NG-F
ELJRE 18NG-F
ELJRE 18NG-F
ELJRE 33NG-F
ELJRE 22NG-F
ELJFC 1R0K-F
ELJFC 2R2K-F
ELJRE 18NG-F
ELJRE R10G-F
ELJRE R10G-F
NL 322522T-471J
NL 322522T-471J
NL 322522T-471J
ELJNC R18K-F
ELJRE 4N7Z-F
ELJRE 3N3Z-F
ELJRE 5N6Z-F
ELJFC 220K-F
ELJRE 5N6Z-F
NL 322522T-471J
ELJRE 22NG-F
ELJRE 22NG-F
MCR10EZHJ 390 Ω (391)
ERJ3GEYJ 102 V (1 kΩ)
MCR10EZHJ 56 Ω (560)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
MCR10EZHJ 1 Ω (010)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 560 V (56 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 560 V (56 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 560 V (56 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 1R0 V (1 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 560 V (56 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 820 V (82 Ω)
ERJ3GEYJ 1R0 V (1 Ω)
ERJ8ENF 47R0V (47 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 273 V (27 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 180 V (18 Ω)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 271 V (270 Ω)
[MAIN UNIT]
REF ORDER
NO. NO.
R96 7030003440 S.RESISTOR
R97 7030003440 S.RESISTOR
R98 7030003460 S.RESISTOR
R99 7030003460 S.RESISTOR
R100 7030003440 S.RESISTOR
R101 7030003490 S.RESISTOR
R102 7030003490 S.RESISTOR
R103 7030003490 S.RESISTOR
R104 7030003400 S.RESISTOR
R106 7030003320 S.RESISTOR
R108 7030003480 S.RESISTOR
R109 7030003320 S.RESISTOR
R110 7030003320 S.RESISTOR
R111 7030003490 S.RESISTOR
R112 7030003490 S.RESISTOR
R113 7030003490 S.RESISTOR
R114 7030003380 S.RESISTOR
R116 7030003320 S.RESISTOR
R122 7030003360 S.RESISTOR
R125 7030003560 S.RESISTOR
R126 7030003640 S.RESISTOR
R127 7030003560 S.RESISTOR
R128 7030003580 S.RESISTOR
R129 7030003280 S.RESISTOR
R130 7030003560 S.RESISTOR
R131 7030003650 S.RESISTOR
R132 7030003360 S.RESISTOR
R133 7030003400 S.RESISTOR
R134 7030003600 S.RESISTOR
R135 7030003440 S.RESISTOR
R136 7030003440 S.RESISTOR
R137 7030003360 S.RESISTOR
R138 7030003280 S.RESISTOR
R139 7030003650 S.RESISTOR
R140 7030003500 S.RESISTOR
R141 7030003440 S.RESISTOR
R145 7030003440 S.RESISTOR
R149 7030003560 S.RESISTOR
R150 7030003560 S.RESISTOR
R151 7030003480 S.RESISTOR
R152 7030003320 S.RESISTOR
R153 7030003480 S.RESISTOR
R154 7030003480 S.RESISTOR
R155 7030003480 S.RESISTOR
R156 7030003320 S.RESISTOR
R157 7030003480 S.RESISTOR
R158 7030003480 S.RESISTOR
R159 7030003560 S.RESISTOR
R160 7030003560 S.RESISTOR
R175 7030003370 S.RESISTOR
R176 7030003500 S.RESISTOR
R177 7030003520 S.RESISTOR
R179 7030003520 S.RESISTOR
R181 7030003320 S.RESISTOR
R182 7030003610 S.RESISTOR
R183 7030004050 S.RESISTOR
R184 7030003520 S.RESISTOR
R185 7030003440 S.RESISTOR
R197 7030003680 S.RESISTOR
R198 7030003400 S.RESISTOR
R199 7030003400 S.RESISTOR
R202 7030003620 S.RESISTOR
R204 7030003400 S.RESISTOR
R206 7030003480 S.RESISTOR
R207 7030003480 S.RESISTOR
R209 7030003380 S.RESISTOR
R219 7030003520 S.RESISTOR
R220 7030003320 S.RESISTOR
R221 7030003640 S.RESISTOR
R222 7030003600 S.RESISTOR
R223 7030003520 S.RESISTOR
R224 7030003480 S.RESISTOR
R225 7030003320 S.RESISTOR
R226 7030003640 S.RESISTOR
R227 7030003600 S.RESISTOR
R228 7030003600 S.RESISTOR
R229 7030003640 S.RESISTOR
R230 7030003520 S.RESISTOR
R231 7030003460 S.RESISTOR
R232 7030003350 S.RESISTOR
R233 7030003700 S.RESISTOR
R234 7030003470 S.RESISTOR
6 - 3
DESCRIPTION
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 273 V (27 kΩ)
ERJ3GEYJ 1R0 V (1 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 181 V (180 Ω)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 182 V (1.8 kΩ)
S.=Surface mount
