Icom IC-PCR100 Service Manual page 21

SOFTWARE ADJUSTMENT (continued)
ADJUSTMENT
• Same operation as step 1 for the listed levels.
S-METER 2
• Set an SSG as:
FM S3
FM S5
FM S7
FM S9
FM S9+20
FM S9+40
FM S9+60
• Receiving
S-METER 1
• Click adjustment item [BPF S] on the Adjustment
FLAT
Panel.
• Select "BPF0" at the left side of Adjustment Panel.
• Set an SSG as
Frequency
Level
Modulation
• Receiving
2 • Same adjustment as step 1 for the listed BPFs frequencies.
BPF 1 – 7.02 MHz
BPF 2 – 21.02 MHz
BPF 3 – 40.02 MHz
BPF 4-1 – 50.02 MHz
BPF 4-2 – 58.28 MHz
BPF 4-3 – 58.32 MHz
BPF 4-4 – 88.02 MHz
BPF 4-5 – 108.28 MHz
BPF 4-6 – 108.32 MHz
BPF 4-7 – 130.02 MHz
BPF 4-8 – 149.98 MHz
BPF 5-1 – 150.02 MHz
BPF 5-2 – 183.28 MHz
BPF 5-3 – 183.32 MHz
• Receiving
NOISE
• Click adjustment item [Noise SQL] on the Adjustment
1
SQUELCH
Panel.
• Display frequency : 149.9700 MHz
• Mode
• Filter
• Set an SSG as
Frequency
Mode
Level
Modulation
Deviation
• Receiving
• Set an SSG as
2
Level
• Receiving
• Filter
3
• Set an SSG as
Level
Modulation
Deviation
• Receiving
• Set an SSG as
4
Level
• Receiving
*This output level of a standard signal generator (SSG) is indicated as SSG's open circuit.
ADJUSTMENT CONDITION
: 1.3 µV* (–105 dBm)
: 3.2 µV* (–97 dBm)
: 13 µV* (–85 dBm)
: 50 µV* (–73 dBm)
: 180 µV* (–62 dBm)
: 630 µV* (–51 dBm)
: 2.5 mV* (–39 dBm)
:
: 1.02 MHz
: 50 µV* (–73 dBm)
: OFF
: FM
: 15 kHz
:
: 149.9700 MHz
: FM
: 0.16 µV* (–123 dBm)
: 1 kHz
: 3.5 kHz
:
: 0.5 µV* (–113 dBm)
: 6 kHz
:
: 0.16 µV* (–123 dBm)
: 1 kHz
: 1.75 kHz
:
: 0.5 µV* (–115 dBm)
WFM S0
WFM S3
WFM S5
WFM S7
WFM S9
WFM S9+20
WFM S9+40
WFM S9+60
• Click "Write" switch to store sampled data into
memory.
BPF 5-4 – 216.02 MHz
BPF 5-5 – 265.68 MHz
BPF 5-6 – 265.72 MHz
BPF 5-7 – 300.02 MHz
BPF 5-8 – 349.98 MHz
BPF 6-1 – 350.02 MHz
BPF 6-2 – 383.28 MHz
BPF 6-3 – 383.32 MHz
BPF 6-4 – 433.32 MHz
BPF 6-5 – 483.28 MHz
BPF 6-6 – 483.32 MHz
BPF 6-7 – 558.32 MHz
BPF 6-8 – 633.28 MHz
BPF 6-9 – 633.32 MHz
• Select "Thresh 15 k" and click "Write" switch for
Thresh level.
• Select "Tight 15 k" and click "Write" switch for Tight
level.
• Select "Thresh 6 k" and click "Write" switch for
Thresh level.
• Select "Tight 6 k" and click "Write" switch for Tight
level.
5 - 8
OPERATION
: 0.79 µV* (–109 dBm)
: 1.6 µV* (–103 dBm)
: 3.2 µV* (–97 dBm)
: 13 µV* (–85 dBm)
: 50 µV* (–73 dBm)
: 180 µV* (–62 dBm)
: 630 µV* (–51 dBm)
: 2.5 mV* (–39 dBm)
BPF 6-10 – 699.98 MHz
BPF 7-1 – 700.02 MHz
BPF 7-2 – 750.02 MHz
BPF 7-3 – 799.98 MHz
BPF 7-4 – 800.02 MHz
BPF 7-5 – 916.68 MHz
BPF 7-6 – 916.72 MHz
BPF 7-7 – 1016.68 MHz
BPF 7-8 – 1016.72 MHz
BPF 7-9 – 1166.68 MHz
BPF 7-10 – 1166.72 MHz
BPF 7-11 – 1299.98 MHz
