[MAIN UNIT]

REF

ORDER

NO.

C269 4030006860 S.CERAMIC

C271 4030007050 S.CERAMIC

C272 4030007010 S.CERAMIC

C273 4030006980 S.CERAMIC

C274 4030011600 S.CERAMIC

C275 4030006860 S.CERAMIC

C276 4030006860 S.CERAMIC

C277 4510006220 S.ELECTROLYTIC

C278 4030011600 S.CERAMIC

C279 4030009510 S.CERAMIC

C280 4030006860 S.CERAMIC

C281 4030007010 S.CERAMIC

C282 4030006860 S.CERAMIC

C284 4030007010 S.CERAMIC

C285 4030009910 S.CERAMIC

C286 4030007030 S.CERAMIC

C287 4030006860 S.CERAMIC

C289 4030011600 S.CERAMIC

C290 4550006250 S.TANTALUM

C291 4030006880 S.CERAMIC

C292 4030012600 S.CERAMIC

C293 4030006880 S.CERAMIC

C294 4030006900 S.CERAMIC

C296 4550000460 S.TANTALUM

C297 4550000460 S.TANTALUM

C298 4510006220 S.ELECTROLYTIC

C299 4550000460 S.TANTALUM

C300 4550000460 S.TANTALUM

C301 4030006860 S.CERAMIC

C304 4030007050 S.CERAMIC

C305 4030007050 S.CERAMIC

C306 4030011600 S.CERAMIC

C307 4030011600 S.CERAMIC

C308 4030011280 S.CERAMIC

C309 4030011600 S.CERAMIC

C310 4030011600 S.CERAMIC

C313 4030011600 S.CERAMIC

C314 4030011600 S.CERAMIC

C315 4030011600 S.CERAMIC

C316 4030011600 S.CERAMIC

C317 4030011330 S.CERAMIC

C318 4030011600 S.CERAMIC

C319 4030011600 S.CERAMIC

C320 4030006880 S.CERAMIC

C324 4030006850 S.CERAMIC

C325 4030011330 S.CERAMIC

C326 4030011330 S.CERAMIC

C327 4030006850 S.CERAMIC

C328 4030011600 S.CERAMIC

C329 4510006220 S.ELECTROLYTIC

C330 4030011600 S.CERAMIC

C331 4030006900 S.CERAMIC

C335 4030007130 S.CERAMIC

C336 4030006860 S.CERAMIC

C337 4030006860 S.CERAMIC

C341 4030006900 S.CERAMIC

C342 4030008880 S.CERAMIC

C343 4030008880 S.CERAMIC

C344 4030011600 S.CERAMIC

C345 4030006900 S.CERAMIC

C346 4510004630 S.ELECTROLYTIC

C347 4030006900 S.CERAMIC

C348 4510004630 S.ELECTROLYTIC

C349 4030006900 S.CERAMIC

C350 4030011600 S.CERAMIC

C351 4030011600 S.CERAMIC

C352 4030011600 S.CERAMIC

C353 4030011310 S.CERAMIC

C354 4030006870 S.CERAMIC

C355 4030011600 S.CERAMIC

C357 4030008770 S.CERAMIC

C358 4510004650 S.ELECTROLYTIC

C359 4030011600 S.CERAMIC

C360 4030006900 S.CERAMIC

C362 4030011600 S.CERAMIC

C363 4030011600 S.CERAMIC

C365 4030011600 S.CERAMIC

C366 4030006850 S.CERAMIC

C367 4030011600 S.CERAMIC

C372 4510005870 S.ELECTROLYTIC

C373 4030006900 S.CERAMIC

C374 4030006880 S.CERAMIC

DESCRIPTION

C1608 JB 1H 102K-T-A

C1608 CH 1H 220J-T-A

C1608 CH 1H 100D-T-A

C1608 CH 1H 070D-T-A

C1608 JB 1C 104KT-N

C1608 JB 1H 102K-T-A

ECEV1CA101UP

C1608 JB 1C 104KT-N

C1608 CH 1H 010B-T-A

C1608 JB 1H 102K-T-A

C1608 CH 1H 100D-T-A

C1608 JB 1H 102K-T-A

C1608 CH 1H 100D-T-A

C1608 CH 1H 040B-T-A

C1608 CH 1H 150J-T-A

C1608 JB 1H 102K-T-A

C1608 JB 1C 104KT-N

TEMSVA 1A 106M-8L

C1608 JB 1H 472K-T-A

C2012 JB 1A 105M-T-A

C1608 JB 1H 472K-T-A

C1608 JB 1E 103K-T-A

TESVA 1C 105M1-8L

ECEV1CA101UP

TESVA 1C 105M1-8L

C1608 JB 1H 102K-T-A

C1608 CH 1H 220J-T-A

C1608 JB 1C 104KT-N

C1608 CH 1H 271J-T-A

C1608 JB 1C 104KT-N

C1608 CH 1H 391J-T-A

C1608 JB 1C 104KT-N

C1608 JB 1H 472K-T-A

C1608 JB 1H 471K-T-A

C1608 CH 1H 391J-T-A

C1608 JB 1H 471K-T-A

C1608 JB 1C 104KT-N

ECEV1CA101UP

C1608 JB 1C 104KT-N

C1608 JB 1E 103K-T-A

C1608 CH 1H 101J-T-A

C1608 JB 1H 102K-T-A

C1608 JB 1E 103K-T-A

C1608 JB 1C 223K-T-A

C1608 JB 1C 104KT-N

C1608 JB 1E 103K-T-A

ECEV1CA100SR

C1608 JB 1E 103K-T-A

ECEV1CA100SR

C1608 JB 1E 103K-T-A

C1608 JB 1C 104KT-N

C2012 JB 1A 564K-T-A

C1608 JB 1H 222K-T-A

C1608 JB 1C 104KT-N

C1608 JB 1H 562K-T-A

ECEV1EA4R7SR

C1608 JB 1C 104KT-N

C1608 JB 1E 103K-T-A

C1608 JB 1C 104KT-N

C1608 JB 1H 471K-T-A

C1608 JB 1C 104KT-N

ECEV1HA3R3SR

C1608 JB 1E 103K-T-A

C1608 JB 1H 472K-T-A

[MAIN UNIT]

REF

ORDER

NO.

C375 4550000550 S.TANTALUM

C376 4030006860 S.CERAMIC

C377 4030011600 S.CERAMIC

C378 4030006880 S.CERAMIC

C387 4030011600 S.CERAMIC

C388 4030011600 S.CERAMIC

C389 4030006860 S.CERAMIC

C390 4030006860 S.CERAMIC

C391 4030011600 S.CERAMIC

C397 4030007170 S.CERAMIC

C398 4030007170 S.CERAMIC

C399 4510004630 S.ELECTROLYTIC

C400 4510004630 S.ELECTROLYTIC

C402 4510004630 S.ELECTROLYTIC

C403 4030006900 S.CERAMIC

C406 4510004650 S.ELECTROLYTIC

C407 4030006900 S.CERAMIC

C408 4030011600 S.CERAMIC

C409 4510006220 S.ELECTROLYTIC

C410 4510004650 S.ELECTROLYTIC

C411 4030006900 S.CERAMIC

C412 4030011600 S.CERAMIC

C413 4510005300 S.ELECTROLYTIC

C414 4510004650 S.ELECTROLYTIC

C415 4030006900 S.CERAMIC

C416 4030011600 S.CERAMIC

C417 4510005300 S.ELECTROLYTIC

C418 4510005630 S.ELECTROLYTIC

C419 4030011600 S.CERAMIC

C420 4510005360 S.ELECTROLYTIC

C421 4510005360 S.ELECTROLYTIC

C422 4030006880 S.CERAMIC

C423 4030006880 S.CERAMIC

C424 4510005360 S.ELECTROLYTIC

C430 4030011600 S.CERAMIC

C431 4030006900 S.CERAMIC

C433 4030007020 S.CERAMIC

C434 4030007020 S.CERAMIC

C435 4030006900 S.CERAMIC

C438 4030004750 S.CERAMIC

C441 4030006900 S.CERAMIC

C442 4510004630 S.ELECTROLYTIC

C443 4030006900 S.CERAMIC

C446 4510004630 S.ELECTROLYTIC

C447 4030006900 S.CERAMIC

C449 4510006220 S.ELECTROLYTIC

C450 4030011600 S.CERAMIC

C451 4510006220 S.ELECTROLYTIC

C452 4510006220 S.ELECTROLYTIC

C453 4510006260 S.ELECTROLYTIC

C454 4510006260 S.ELECTROLYTIC

C455 4030011810 S.CERAMIC

C456 4030011810 S.CERAMIC

C457 4030012610 S.CERAMIC

C458 4030010760 S.CERAMIC

C459 4030007010 S.CERAMIC

C460 4030010760 S.CERAMIC

C461 4030012610 S.CERAMIC

C462 4030007010 S.CERAMIC

C463 4030012610 S.CERAMIC

C464 4030006870 S.CERAMIC

C465 4030012610 S.CERAMIC

C466 4030006870 S.CERAMIC

C467 4550006250 S.TANTALUM

C468 4030011600 S.CERAMIC

C469 4030011600 S.CERAMIC

C470 4030011600 S.CERAMIC

C473 4030006860 S.CERAMIC

C474 4030006900 S.CERAMIC

C477 4030007130 S.CERAMIC

C478 4030007130 S.CERAMIC

C479 4030007010 S.CERAMIC

C481 4030006860 S.CERAMIC

C482 4030006860 S.CERAMIC

C483 4030006860 S.CERAMIC

C488 4030009520 S.CERAMIC

C490 4030006860 S.CERAMIC

C491 4030006860 S.CERAMIC

C493 4030006860 S.CERAMIC

C496 4030007030 S.CERAMIC

C500 4030006860 S.CERAMIC

C501 4030006860 S.CERAMIC

6 - 7

DESCRIPTION

TESVA 1V 224M1-8L

C1608 JB 1H 102K-T-A

C1608 JB 1C 104KT-N

C1608 JB 1H 472K-T-A

C1608 JB 1C 104KT-N

C1608 JB 1H 102K-T-A

C1608 JB 1C 104KT-N

C1608 CH 1H 221J-T-A

ECEV1CA100SR

C1608 JB 1E 103K-T-A

ECEV1EA4R7SR

C1608 JB 1E 103K-T-A

C1608 JB 1C 104KT-N

ECEV1CA101UP

ECEV1EA4R7SR

C1608 JB 1E 103K-T-A

C1608 JB 1C 104KT-N

ECEV1AA330SR

ECEV1EA4R7SR

C1608 JB 1E 103K-T-A

C1608 JB 1C 104KT-N

ECEV1AA330SR

ECEV1EA330SP

C1608 JB 1C 104KT-N

ECEV1HA4R7SR

C1608 JB 1H 472K-T-A

ECEV1HA4R7SR

C1608 JB 1C 104KT-N

C1608 JB 1E 103K-T-A

C1608 CH 1H 120J-T-A

C1608 JB 1E 103K-T-A

C2012 JB 1H 103K-T-A

C1608 JB 1E 103K-T-A

ECEV1CA100SR

C1608 JB 1E 103K-T-A

ECEV1CA100SR

C1608 JB 1E 103K-T-A

ECEV1CA101UP

C1608 JB 1C 104KT-N

ECEV1CA101UP

ECEV1AA471UP

C1608 JB 1A 224K-T-N

C2012 JB 1C 474K-T-A

C1608 CH 1H 331J-T-A

C1608 CH 1H 100D-T-A

C1608 CH 1H 331J-T-A

C2012 JB 1C 474K-T-A

C1608 CH 1H 100D-T-A

C2012 JB 1C 474K-T-A

C1608 JB 1H 222K-T-A

C2012 JB 1C 474K-T-A

C1608 JB 1H 222K-T-A

TEMSVA 1A 106M-8L

C1608 JB 1C 104KT-N

C1608 JB 1H 102K-T-A

C1608 JB 1E 103K-T-A

C1608 CH 1H 101J-T-A

C1608 CH 1H 100D-T-A

C1608 JB 1H 102K-T-A

C1608 CH 1H 020B-T-A

C1608 JB 1H 102K-T-A

C1608 CH 1H 150J-T-A

C1608 JB 1H 102K-T-A

S.=Surface mount
