Smart SAM2W User Guide V1.2

6.2 RJ45 Socket

Pin Signals
1 VIN
2 DCD
3 DTR
4 GND
5 RXD
6 TXD
7 CTS
8 RTS
6.3 FME-Male 50Ω Antenna Connector
The FME male antenna connector is a 50Ω impedance antenna connector. The antenna used for the Smart
SAM2W must have 50Ω impedance.

6.4 SIM Holder

The SIM holder is designed to accommodate a mini-SIM card. The SIM card can either be 3V or 1V8 SIM. To
insert the SIM card, remove the door by sliding it back toward the end. Make sure the SIM card faces the
right way as indicated on the box. Voltage levels over this SIM interface complies with 3GPP standards

6.5 LED Status

The LED indication has the following status:
- LED on steady: No SIM card or no SIM PIN or Network search in progress.
- 200ms on/ 2sec off: Idle mode, registered to the GSM network.
- 200ms on/600ms off: CSD or PSD data transfer in progress.
- 100ms on/200ms off: The downloaded firmware is either not compatible or corrupted.
- LED is off permanently : No power
9
Description
Input Voltage 5Vdc - 32Vdc
Data Carrier Detect
Data Terminal Ready
Common Ground
Serial Data out of the Smart SAM2W
Serial Data into the Smart SAM2W
Clear to Send
Ready to Send
Ver1.2
