RJ45 Socket

6.2
Pin Signals
1 VIN
2 DCD
3 DTR/RI
4 GND
5 RXD
6 TXD
7 CTS
8 RTS

Mini USB Connector

6.3
Pin Signal
1 Vusb
2 D-
3 D+
4 N/C
5 GND
FME-Male 50Ω Antenna Connector
6.4
The FME male antenna connector is a 50Ω impedance antenna connector. The antenna used for the Smart
SAM4Q must have 50Ω impedance.

SIM Holder

6.5
The SIM holder is designed to accommodate a mini-SIM card. The SIM card can either be 3V or 1V8 SIM. To
insert the SIM card, remove the door by sliding it back towards the end. Make sure the SIM card faces the right
way as indicated on the box. Voltage levels over this SIM interface complies with 3GPP standards.

LED Status

6.6
The LED indicator has the following status for different SAMMODE:
SAMMODE=0
-Modem power on: Green Led on permanently
-IP connected on 4G band: Green Led 100ms on 3000ms off
SAMMODE=1
-First power on until SIM ready: Green LED on permanently
9
Description
Input voltage 5Vdc - 32Vdc
Data Carrier Detect
Data terminal Ready/Ring Indicator
Common Ground
Serial Data out of the Smart SAM4Q
Serial Data into the Smart SAM3
Clear to Send
Ready to Send
