6.2

The RJ45 socket

Pin Signals
1 VIN
2 DCD
3 DTR/RI
4 GND
5 RXD
6 TXD
7 CTS
8 RTS
7.1 The FME-Male 50Ω antenna connector
The FME male antenna connector is a 50Ω impedance antenna connector. The antenna used for the
Smart SAM3S must have 50Ω impedance.

6.4 The SIM holder

The SIM holder is designed to accommodate a mini-SIM card. The SIM card can either be 3V or 1V8
SIM. To insert the SIM card, remove the door by sliding it back toward the end. Make sure the SIM card
faces the right way as indicated on the box. Voltage levels over this SIM interface complies with 3GPP
standards
6.5

The LED status

The LED indication has the following status:
Note: the LED status can be changed using AT^SLED command.
Status
GSM CS data call in progress or
UMTS data transfer
UE registered to a network. No call, no
data transfer
Limited Network Service (e.g. because no
SIM/ USIM, no PIN or during network search)
Description
Input voltage 5Vdc - 32Vdc
Data Carrier Detect
Data terminal Ready/Ring Indicator
Common Ground
Serial Data out of the Smart SAM3S
Serial Data into the Smart SAM3S
Clear to Send
Ready to Send
Mode 1
Permanently
on
Permanently
on
Permanently
on
500ms on
500ms off
Intercel Pty. Ltd. A.C.N. 007 077 161
33 Glenvale Crescent
Mulgrave VIC. Australia 3170
Email : intercel@intercel.com.au
Internet : www.intercel.com.au
Ph : 61 3 9239 2000 Fax : 61 3 9561 2614
Mode 2
10ms on
990ms off
10ms on
1999ms off
10ms on
3999ms off
500ms on
500ms off
Mode 3
<flash>ms on
990ms off
<flash>ms on
1999ms off
<flash>ms on
3999ms off
500ms on
500ms off
