ELECTRIC HEIGHT-ADJUSTED SIT TO STAND DESK
Flex Pro Series Assembly Guide
Table of Contents
CAUTION, USE & LIABILITY .......................................................................................................................... 2
PARTS & HARDWARE LIST ........................................................................................................................... 3
PARTS / COMPONENT DIAGRAMS ......................................................................................................... 4
ASSEMBLY INSTRUCTIONS ........................................................................................................................ 5
BLUETOOTH ..................................................................................................................................................... 10
TROUBLESHOOTING ................................................................................................................................... 11
WARRANTY INFORMATION ....................................................................................................................... 12
Advertisement
Related Manuals for ApexDesk Flex Pro Series
Summary of Contents for ApexDesk Flex Pro Series
-
Page 1: Table Of Contents
ELECTRIC HEIGHT-ADJUSTED SIT TO STAND DESK Flex Pro Series Assembly Guide Table of Contents CAUTION, USE & LIABILITY .......................... 2 PARTS & HARDWARE LIST ........................... 3 PARTS / COMPONENT DIAGRAMS ......................4 ASSEMBLY INSTRUCTIONS ........................5 BLUETOOTH ..............................10 TROUBLESHOOTING ........................... 11... -
Page 2: Caution, Use & Liability
The desk height is adjustable so that it can be positioned at the most suitable height. Any other use is at user’s risk. Under no circumstances does the manufacturer accept warranty claims or liability claims for damages caused from improper use or handling of the desk. Flex Pro Series Assembly Guide P a g e... -
Page 3: Parts & Hardware List
Phillips Screwdriver 4mm Allen Wrench Phillips screwdriver (not provided) Ref # DESCRIPTION IMAGE M6x15mm Machine Screw w/Lock & Flat Washer 5x20mm Wood Screw 4mm Set Screw 4mm Allen Wrench M6x20mm Machine Screw Flex Pro Series Assembly Guide P a g e... -
Page 4: Parts / Component Diagrams
PARTS / COMPONENT LIST Lifting column Foot Adjustable Frame Adjustable Connecting Bar Top Support Bracket Control box 2-button or Memory Height Controller Motor Cable (not shown) Cable Management Tray Power Cord (not shown) Flex Pro Series Assembly Guide P a g e... -
Page 5: Assembly Instructions
3) Align outer screw holes with Desk Support Bracket, and insert 2 machine screws (E1) to each side of the leg. 4) Each leg is secured by 4 machine screws (E1) with 2 pre-installed. Make sure to tighten all 4 screws. Flex Pro Series Assembly Guide P a g e... - Page 6 Use 4mm Allen wrench to secure each foot to column with four machine screws (E1) and washers. Insert 8 set screws (E3) into the frame – 4 on each side. Don’t tighten those screws now. Flex Pro Series Assembly Guide P a g e...
- Page 7 2. Use provided Wood Screws to secure the frame to your own top. If you are using own screws, please check the length and make sure they do not go through the top. 3. Follow 1 to 5 under STEP 3A. Flex Pro Series Assembly Guide P a g e...
- Page 8 Make sure no obstacles are in the desk’s path. Make sure the desktop is not touching any walls. Make sure all cords are appropriate length to accommodate the change in height. Flex Pro Series Assembly Guide P a g e...
- Page 9 OVERHEAT: To avoid overheating, don’t move the desk up and down continuously for over two minutes within any 20 minute period. If the desk overheats, LED will display OH. Stop using the desk for 10 minutes and let the desk cool down. Flex Pro Series Assembly Guide P a g e...
-
Page 10: Bluetooth
Setting Icon Reset Icon INSTALL APP TO YOUR PHONE: Search Apexdesk in Apple or Google APP store and download APP to your phone. Apexdesk logo will appear on your phone once downloaded. CONNECTING TO DESK VIA BLUETOOTH: Open APP on your phone and stay within 15 feet of the desk. Devices ADJUST163xxxx will appear on your phone screen. -
Page 11: Troubleshooting
The message is displayed on the controller as ER1 or ER2. Switch device) motor cables at control box and reset the desk. If the problem persists, replace motor cables and reset. Flex Pro Series Assembly Guide 11 | P a g e... -
Page 12: Warranty Information
ApexDesk’s obligation under this warranty is limited to the repair or replacement, at ApexDesk’s sole option, of the parts or products the defect of which are reported to ApexDesk within the applicable warranty period and which, upon examination by ApexDesk, prove to be defective.
