Wall Direct Monitor Mount
COMPONENT CHECKLIST
A
Wall direct
assembly
(x1)
F
Security Screw
M4 x 16mm
(x1)
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! This product is designed to support a flat panel monitor in a non interactive environment. i.e. It should not be used in a situation
where the display's position will be frequently change.
! The manufacturer accepts no responsibility for incorrect installation.
B
C
VESA
5mm
head
Allen key
(x1)
(x1)
G
Mounting
Mounting
screws
screws
M4 x 10mm
M4 x 12mm
(x4)
(x4)
D
E
Countersunk
Wall plug
Screw
(x2)
M6 x 50mm
(x2)
H
I
Mounting
screws
M4 x 16mm
(x4)
Installation Guide
AF-WD
REQUIRED TOOLS
• Phillips Head Screwdriver
• Drill Bit
• Power Drill
WEIGHT RANGE
0 - 8kg
(0 - 17.6lbs)
AF-WD Page 1 of 2
Advertisement
Table of Contents
Related Manuals for Atdec AF-WD
Summary of Contents for Atdec AF-WD
-
Page 1: Installation Guide
! This product is designed to support a flat panel monitor in a non interactive environment. i.e. It should not be used in a situation where the display’s position will be frequently change. ! The manufacturer accepts no responsibility for incorrect installation. AF-WD Page 1 of 2... - Page 2 No portion of this document or any artwork contained herein should be reproduced in any way without the express written consent of Atdec Pty Ltd. Due to continuing product development, the manufacturer reserves the right to alter specifications without notice. ©20180228B AF-WD Page 2 of 2 atdec.com | atdec.co.uk | atdec.com.au...
