Micro Desktop Monitor Mount - C Clamp
COMPONENT CHECKLIST
A
VESA
head
(x1)
B
Pole
Assembly
(x1)
C
Desk Clamp
(x1)
IMPORTANT INFORMATION
! Please ensure this product is installed as per these installation instructions.
! The manufacturer accepts no responsibility for incorrect installation.
D
E
Pressure
Screw
Plate
M8x30mm
(x1)
(x1)
I
J
Screw
2mm
M8x60mm
Allen Key
(x1)
(x1)
N
O
Mounting
Mounting
Screws
Screws
M4x10mm
M4x12mm
(x4)
(x4)
F
G
Pole
Bolt Through
Cap
Plate
(x1)
(x1)
K
L
5mm
Cable
Cable
Allen Key
Clip
Stop
(x1)
(x1)
(x2)
P
Q
Mounting
Security
Screws
Screw
M4x16mm
M4 x 16mm
(x4)
(x1)
Installation Guide
H
Steel
Washer
(x1)
REQUIRED TOOLS
• Power Drill
M
• Drill Bit
• Phillips Head Screwdriver
WEIGHT RANGE
AF-MC
0 - 8kg
(0 - 17.6lbs)
AF-MC Page 1 of 4
