Service and Replacement
Parts Manual
MANUAL MC-425-13
Model Numbers:
C0-425-48
T h e B e s t W a y
T o G o
A b o u t Y o u r
B u s i n e s s
WARNING
READ THE OPERATOR'S MANUAL BEFORE OPERATING
THIS VEHICLE.
The operator's manual contains important information
regarding the safe operation of this vehicle.
Starting Serial Number: 204740
D
Ending Serial Number: See Introduction Chapter
