USER MANUAL
®
Mobeye
PowerGuard
CM2100
SW version 4.n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerGuard CM2100 and is the answer not in the manual?

Questions and answers

Related Manuals for Mobeye PowerGuard CM2100

Summary of Contents for Mobeye PowerGuard CM2100

  • Page 1 USER MANUAL ® Mobeye PowerGuard CM2100 SW version 4.n...

  • Page 3: Table Of Contents

    Power failure delay time 5.12 Power failure message 5.13 Automatic arming / disarming 5.14 Buttonlock 5.15 Low power mode 5.16 Test message 5.17 System reset Request list of the status, settings and signal strength Mobeye Internet Portal Technical messages and status feedback...
  • Page 4 • Do not use in an environment where any inflammable gases, vapors or dust are present or could be present. ® • Repair of the device may only be carried out by people, trained for Mobeye repair. • If the device must be repaired, only original replacement components may be used. The ®...

  • Page 5: General Description

    - When the power is restored, the Mobeye PowerGuard sends a ‘power restored’ SMS text message. - When one of the inputs is activated by a sensor, the Mobeye PowerGuard sends an alarm SMS text message and calls the phone numbers programmed in by the user.

  • Page 6: Getting Started

    2. GETTING STARTED To get started with the Mobeye PowerGuard, at least the following steps need to be taken in the following order: 1. Insert a SIM card 2. Insert the batteries 3. Connect an external power supply 4. Program at least one telephone number 5.

  • Page 7: Connect An External Power Supply

    - V+ (black lead with white stripe) to “+” - Ground (black lead) to “-“ As soon as the batteries are placed and the power source is connected, the Mobeye PowerGuard switches to the program mode. First the GSM module establishes network connection.

  • Page 8: Switching On/Off

    2.5 SWITCHING ON/OFF After the previous steps, the Mobeye PowerGuard is ready for use. It is armed (switched on) automatically. In order to switch off (disarm) the Mobeye PowerGuard: - Press the on/ off button at the upper side for 1 second. The green LED switches off to indicate the disarmed status.

  • Page 9: Connect Sensors To The Inputs

    3. CONNECT SENSORS TO THE INPUTS Two external sensors can be connected to the inputs. As a standard reaction after a triggered input, the Mobeye PowerGuard sends an SMS text message to the preset numbers and calls these numbers. Insert the 2 wires of an external sensor through...

  • Page 10: Configuration

    4. CONFIGURATION To program the Mobeye PowerGuard, the GSM module must have network connection. In case only batteries are used, first switch the unit to the program mode. Next send SMS commands for the configuration. All settings are stored and will be kept in the unit, even in case the power supplies are removed.

  • Page 11: The (Security) Code

    4.2 THE (SECURITY) CODE For configuration activities the (security) code of the Mobeye PowerGuard must be used. The initial (security) code is ‘1111’. You can change the (security) code to your own code. See section 4.4. 4.3 PROGRAMMING THE SETTINGS BY SMS To program the settings by SMS text message: 1.

  • Page 12: List Of Sms Commands For Configuration

    INSTCODE: 0000···9999 1111 Set telephone number for TEL1: Empty …. alarm messages TEL5: Delete telephone number DEL1 …. DEL5 Mobeye Identification text NAME: 20 characters Call on/off CALL: ON, OFF SMS on/off SMS: ON, OFF Input type input 1 TYPEIN1:...
  • Page 13 Setting SMS Command Options Default value Assigning times 1 DAYS1: 1234567 Empty Assigning times 2 DAYS2: 1234567 Empty Use of on/off button BUTTONLOCK: (button locked) (unlocked) Low power status LOWPOWER: ON, OFF Interval ‘test SMS’ TEST: 0···30 (days) Time test message TESTTIME: hhmm Examples:...

  • Page 14: Possible Settings

    5. POSSIBLE SETTINGS 5.1 PHONE NUMBERS The Mobeye PowerGuard is able to send alarm messages to up to 5 phone numbers. The first telephone number (TEL1) belongs to the administrator. Only this number receives all system messages. The other phone numbers (including the administrator) only get the alarm messages.

  • Page 15: Alarm Texts

    5.3 ALARM TEXTS Unique alarm texts can be programmed into the Mobeye PowerGuard. User defined texts have a maximum length of 20 characters. Following default texts are programmed: Text 1 (input Alarm 1 Text 2 (input 2): Alarm 2 Text 3 (power failure):...

  • Page 16: Input Type

    5.6 INPUT TYPE The input type defines the character of the inputs IN1 and IN2. This can be Normally Open (NO) or Normally Closed (NC). If an input is set to NO, the alarm will be triggered as soon as the terminals of the input are closed. If the input is set to NC, the alarm is triggered when the connection between the input terminals is broken.

  • Page 17: Inactive Time

    1111 REPEAT:20 5.11 POWER FAILURE DELAY TIME If the Mobeye PowerGuard is powered externally and the power fails it can notify the contact person(s). The power failure delay time defines the time between the initial power failure and the alarm notification. If the power is restored within the delay time, no alarm is sent.

  • Page 18: Power Failure Message

    1111 POWERMESSAGE:ALERT 5.13 AUTOMATIC ARMING / DISARMING The Mobeye PowerGuard only works if the unit is armed, which is done via the on/off button. It is possible to automatically arm and disarm the unit, based on an arming and/or disarming time scheme . Two schemes can be entered, which can be assigned to the days in the week (e.g.

  • Page 19: Buttonlock

    To set a daily disarming scheme: SMS command disarming scheme 1: TIMEDISARM1: To set a second daily arming scheme: SMS command arming scheme 2: TIMEARM2: To set a second daily disarming scheme: SMS command disarming scheme 2: TIMEDISARM2: example: TIMEDISARM2:1455 As default the automatic (dis) arming times are valid for all days.

  • Page 20: Low Power Mode

    1111 LOWPOWER:ON 5.16 TEST MESSAGE The Mobeye PowerGuard can send regular test SMS messages (keep alive) to the administrator (first phone number), to ensure the proper functioning of the unit. The test message function is only active if the unit is armed. The timing of the test message is determined by the time of programming.

  • Page 21: Request List Of The Status, Settings And Signal Strength

    6. REQUEST LIST OF THE STATUS, SETTINGS AND SIGNAL STRENGTH Several lists and status reports can be retrieved by sending an SMS text message to the Mobeye PowerGuard, from any telephone. Before sending the request, make sure the unit is in the program mode (please refer to 4.1).

  • Page 22: Mobeye Internet Portal

    7. MOBEYE INTERNET PORTAL The Mobeye PowerGuard sends GSM messages to the preset contact persons. It is also possible to connect the system to the Mobeye Internet Portal. In this secured internet environment the Mobeye PowerGuard system(s) can be administered.

  • Page 23: Technical Messages And Status Feedback

    8. TECHNICAL MESSAGES AND STATUS FEEDBACK Technical messages In the event of technical issues the administrator receives an SMS message. Possible technical messages are: Message Reason Low batteries, external power Power is available, batteries need to be supply OK replaced. No external power supply, No external power supply, batteries are able to batteries OK...
  • Page 24 Status feedback LED pattern Status Required action Blinking green, 1 second Module not configured Configure at least one on / 1 second off telephone number. 1 green flash every 3 Module is switched on, No action required. seconds powered by batteries Green LED stays on Module is switched on, No action required.
  • Page 25 Publisher. Reprinting, even in summary, is prohibited. This user manual meets the technical requirements at the moment of printing. Changes in technology and equipment are reserved. © Copyright 2017 by Mobeye, version CM2100EN170501 V4.20+...
