- Page 1 USER MANUAL Mobeye CM-Guard-40 ® CM4040 SW version 2.n...
- Page 3 Connect a sensor to the input Insert the batteries Connect an external power supply (optionally) Network connection and program mode 4. Programming when using the Mobeye SIM and portal Sign up in the Mobeye Internet Portal Register the Mobeye SIM card Configuration and synchronisation...
- Page 4 • Do not let it fall from height. • Do not use in an environment where any inflammable gases, vapors or dust are present or could be present. • Repair of the device may only be carried out by people, trained for Mobeye ® repair.
- Page 5 In order to activate the device, a few steps are to be followed. First of all, you need to insert a SIM card. With the Mobeye SIM card, the CM4040 uses the 4G LTE-M network. This network has a strong network coverage, deep penetrability in buildings and also works in remote areas.
- Page 6 The Mobeye CM4040 with Mobeye SIM card and registered on the Mobeye Internet Portal, has the following behaviour as factory settings: - In case one of the inputs is activated by a sensor, the Mobeye CM4040 sends an alarm message to the Mobeye Internet Portal. The Portal forwards the alarm as push notification, call (spoken message), text message and/or e-mail to the ‘alarm contacts’.
- Page 7 The Mobeye CM4040, equipped with your own SIM card, has the following standard behavior as factory settings: - When one of the inputs is activated by a sensor, the Mobeye CM4040 sends an alarm SMS text message and calls the phone numbers programmed in by the user.
- Page 8 3. GETTING STARTED To get started with the Mobeye CM4040, at least the following steps need to be taken in the following order: 1. Open the casing and insert the SIM card 2. Connect a sensor to the input 3. Insert the batteries 4.
- Page 9 When using the Mobeye SIM card: The Mobeye SIM card is PIN code secured and will only work in a Mobeye device. Please do not place it in another device. When using your own SIM card: An own SIM card has a “micro” format, is suitable for the 2G network and can make calls and send text messages.
- Page 10 3.5 NETWORK CONNECTION AND PROGRAM MODE After placing the batteries (and external power) the Mobeye CM4040 will search for the network. The outside LED flashes green and red. This process normally takes 10-30 seconds, in a new device this can take some minutes.
- Page 11 sec. off in case the unit has not been configured yet). In a battery-operated unit a time-out occurs after 3 minutes, after which the communication module switches off in order to save the batteries. In this low power mode the LED flashes once per 3 seconds. It will search for network connection once it needs to send notifications.
- Page 12 Follow the instructions on the screen. You will receive an e-mail to confirm the new account. After confirmation login on the portal. If you do not receive this e-mail, please check your spam box or ask Mobeye (info@mobeye.com). 4.2 REGISTER THE MOBEYE SIM CARD...
- Page 13 4.3 CONFIGURATION AND SYNCHRONISATION The device settings can be programmed in the Mobeye Internet Portal. In this way you prepare the settings, to be picked up by the device. Since the Mobeye device is leading in the communication between the portal and the device, the data synchronisation is done after: 1) any message to the portal (regular test message, alarm, low batteries).
- Page 14 Device Settings The device settings can be changed via the Mobeye Internet Portal. To do this, click on the "edit" icon and type in the security code (factory setting is "1111"). See chapter 5 for the description per setting. After saving the new settings, they must be retrieved by the device (synchronized).
- Page 15 The message texts can be adapted to your own text. 4.5 HOW TO ACTIVATE THE CM4040 After the previous steps the Mobeye CM4040 is ready for use. It is armed automatically. In order to switch off (disarm) the Mobeye CM4040: - Press the button at the backside for 1 second.
- Page 16 The SIM card is now disconnected and is visible on the "Add device" screen. The SIM card can be used again in another (or the same) Mobeye device in combination with the portal. Note: If an own SIM card has been used in the device first, a factory reset is...
- Page 17 5. POSSIBLE SETTINGS The Mobeye CM4040 has many setting options that influence the behaviour of the module. If connected on the Mobeye Internet Portal, the settings are prepared in the portal (see chapter 4). If your own SIM card is used, programming is done via SMS commands (see chapter 6).
- Page 18 It is possible to connect a sensor with an analog output value between 1V and 48V, by placing a resistor or relay between the sensor and the input. For an explanation, see the support page on www.mobeye.com. 5.4 ALARM DELAY TIME The input delay time defines the time that the input is triggered before an alarm is initiated.
- Page 19 "0". 5.10 AUTOMATIC ARMING / DISARMING The Mobeye CM4040 only works if the unit is armed, which is done via the on/off button. It is possible to automatically arm and disarm the unit, based on an arming and/or disarming time scheme. Two schemes can be entered, which can be assigned to the days in the week (e.g.
- Page 20 5.15 NOTIFICATION TO PRIVATE EMERGENCY CENTER The Mobeye CM4040 can send the reports to a control room using the standard SIA DC09 protocol. This requires the use of the Mobeye SIM/Portal.
- Page 21 If the CM4040 is connected to an external power supply, it has continuous network connection and is permanently in program mode. A battery-operated Mobeye CM4040 switches to the program mode after re- inserting the batteries or pressing the button at the back for 5 seconds.
- Page 22 LTE-M network. 6.4 PROGRAM AT LEAST ONE TELEPHONE NUMBER The Mobeye CM4040 is able to send messages up to 5 telephone numbers. The first telephone number (TEL1) is mandatory. This number will receive, next to alarm message, also system messages such as battery low and keep- alive message.
- Page 23 . . . TEL5: Delete telephone DEL1 number . . . DEL5 Identification text NAME: 20 characters Mobeye Interval ‘test SMS’ TEST: 0 ··· 30 (days) Time test message TESTTIME: hhmm Input type input 1 INPUTTYPE:1= NO, NC, OFF Input type input 2...
- Page 24 Setting SMS command Options Default value 2nd disarming time TIMEDISARM2: hhmm Empty Assigning times 1 DAYS1: 1234567 Empty Assigning times 2 DAYS2: 1234567 Empty Use of on/off button BUTTONLOCK: ON (button locked) OFF (unlocked) Low power status LOWPOWER: ON, OFF Call on/off CALL: ON, OFF...
- Page 25 7.2 HOW TO ACTIVATE THE CM4040 After the previous steps the Mobeye CM4040 is ready for use. It is armed automatically. In order to switch off (disarm) the Mobeye CM4040: - Press the button at the backside for 1 second. The green LED switches off to indicate the disarmed status.
- Page 26 Mobeye CM4040, from any telephone number. Before sending the request, make sure the unit is in the program mode (see 6.1). Upon sending the command, the Mobeye CM4040 returns an SMS text message to the originator of the request. The commands are case insensitive.
- Page 27 7.5 TECHNICAL MESSAGES In the event of technical issues the telephone number programmed in at position 1 (TEL1) receives an SMS message. Possible technical messages are: Message Reason Low batteries, external power Power is available, batteries need to be replaced. supply OK No external power supply, No external power supply, batteries are able to take...
- Page 28 Check SMS command. action 4 red flashes every 3 sec., Low batteries Replace both batteries. short green in between Flashes green/red Retrieving new firmware Wait fifteen minutes. simultaneously from Mobeye server Quickly flashing green Module exchanges data No action required with portal...
- Page 29 This product is designed and manufactured in the Netherlands. For more information, visit www.mobeye.com. ® This manual is published by Mobeye All rights, the translation included are reserved. Any reproduction, either photocopy, microfilm or saved in an automated data dictionary, only after written approval of the Publisher.
