  • Page 1 USER MANUAL ® Mobeye ThermoGuard CM2200 SW version 4.n...
  • Page 3 • Do not use in an environment where any inflammable gases, vapors or dust are present or could be present. ® • Repair of the device may only be carried out by people, trained for Mobeye repair. • If the device must be repaired, only original replacement components may be used. The use ®...

  • Page 4: Table Of Contents

    CONTENT 1. General description 2. Getting started Insert a SIM card Connect the temperature sensor(s) Insert the batteries Enter the program mode Program at least one telephone number Program threshold values for the inputs Switching on/off Confirmation of the alarm message 3.
  • Page 5 5.18 Test message 5.19 System reset 6. Request list of the status, settings and signal strength 7. Technical messages and status feedback 8. Mobeye Internet Portal...

  • Page 6: General Description

    ‘Temperature OK’. - When one of the inputs is activated by a sensor, the Mobeye ThermoGuard sends an alarm SMS text message and calls the phone numbers programmed in by the user.

  • Page 7: Getting Started

    2. GETTING STARTED To get started with the Mobeye ThermoGuard, at least the following steps need to be taken in the following order: 1. Insert a SIM card 2. Connect the temperature sensor 3. Insert the batteries 4. Enter the program mode 5.

  • Page 8: Connect The Temperature Sensor(S)

    1 sec. on/1 sec. off (or stays on continuously in case the first telephone number has been configured). The Mobeye ThermoGuard returns to the program mode by pressing the on/off button for 5 seconds, until the LED starts flashing red/green. Once it has GSM connection it will be flashing again (or stays on continuously).

  • Page 9: Program At Least One Telephone Number

    2.5 PROGRAM AT LEAST ONE TELEPHONE NUMBER The Mobeye ThermoGuard is able to send messages up to 5 telephone numbers. The first telephone number (TEL1) belongs to the administrator. Technical messages (such as battery low) are sent to the administrator only. Without the administrators’ phone number, the Mobeye ThermoGuard cannot function.

  • Page 10: Switching On/Off

    2.7 SWITCHING ON/OFF After the previous steps, the Mobeye ThermoGuard is ready for use. It is armed (switched on) automatically. In order to switch off (disarm) the Mobeye ThermoGuard: - Press the on/ off button at the upper side for 1 second. The green LED switches off to indicate the disarmed status.

  • Page 11: Use Of External Power Supply And Inputs

    3. USE OF EXTERNAL POWER SUPPLY AND INPUTS 3.1 USE OF EXTERNAL POWER SUPPLY Although the Mobeye ThermoGuard is designed to run on batteries, it is possible to use an external power supply. In this mode the module is always connected with the GSM network and therefore always in program mode.
  • Page 12 input 1 (press on the green pins for connecting the wires). It does not matter which wire is connected to which connector. When using a second input, connect this to input 2. As default the inputs are programmed as Normally Open (NO) contacts. This means the inputs are triggered if the input is closed for at least 1 second.

  • Page 13: Configuration

    4. CONFIGURATION To program the Mobeye ThermoGuard, the GSM module must have network connection. In case only batteries are used, first switch the unit to the program mode. Next send SMS commands for the configuration. All settings are stored and will be kept in the unit, even in case the power supplies are removed.

  • Page 14: The (Security) Code

    4.2 THE (SECURITY) CODE For configuration activities the (security) code of the Mobeye ThermoGuard must be used. The initial (security) code is ‘1111’. You can change the (security) code to your own code. See section 4.4. 4.3 PROGRAMMING THE SETTINGS BY SMS To program the settings by SMS text message: 1.

  • Page 15: List Of Sms Commands For Configuration

    TEL5: Delete telephone number DEL1 … DEL5 Lower limit temperature LTL: -35··· 70 (ºC) Upper limit temperature HTL1: -35··· 70 (ºC) Mobeye Identification text NAME: 20 characters Call on/off CALL: ON, OFF SMS on/off SMS: ON, OFF Input type input 1...
  • Page 16 Setting SMS Command Options Default value Alarm text power failure TEXT6: 20 characters Power failure Power restored Text at power restore TEXT7: 20 characters Power failure delay time DELAYPOW: 0···999 (min) Power message ALARM POWERMESSAGE: OFF,ALERT,ALARM Actual time TIME: hhmm Empty Actual date DATE:...

  • Page 17: Possible Settings

    5. POSSIBLE SETTINGS 5.1 PHONE NUMBERS The Mobeye ThermoGuard is able to send alarm messages to up to 5 phone numbers. The first telephone number (TEL1) belongs to the administrator. Only this number receives all system messages. The other phone numbers (including the administrator) only get the alarm messages.

  • Page 18: Identification Text

    It is possible to add a standard identification text (NAME) to all messages sent out by the Mobeye ThermoGuard. The alarm messages are a combination of the name and the alarm text. A user defined identification has a length of maximum 20 characters. The default identification text is ‘Mobeye’.

  • Page 19: Call On/Off

    5.6 CALL ON/OFF By default, the Mobeye ThermoGuard sends alarm notifications via text message and calls the preset contact persons. By turning off the CALL, the unit will only send an SMS text message as alarm notification. It is not possible to switch off both the SMS and the call.

  • Page 20: Inactive Time

    1111 REPEAT:20 5.12 POWER FAILURE DELAY TIME If the Mobeye ThermoGuard is powered externally and the power fails it can notify the contact person(s). The power failure delay time defines the time between the initial power failure and the alarm notification. If the power is restored within the delay time, no...

  • Page 21: Power Failure Message

    1111 DELAYPOW:15 5.13 POWER FAILURE MESSAGE If the Mobeye ThermoGuard is powered externally and the power fails it sends an SMS text message to the programmed telephone numbers followed by a call (setting ‘ALARM’), following the on/off settings of ‘CALL’ and ‘SMS’. Power restore results in an SMS alert to all numbers.

  • Page 22: Automatic Arming / Disarming

    1111 TOFFSET:0,5 5.16 AUTOMATIC ARMING / DISARMING The Mobeye ThermoGuard only works if the unit is armed, which is done via the on/off button. It is possible to automatically arm and disarm the unit, based on an arming and/or disarming time scheme. Two schemes can be entered, which can be assigned to the days in the week (e.g.

  • Page 23: Buttonlock

    1111 BUTTONLOCK:ON 5.18 TEST MESSAGE The Mobeye ThermoGuard can send regular test SMS messages (keep alive) to the first phone number (TEL1), to ensure the proper functioning of the unit. The test message contains the actual temperature. The test message function is only active if the unit is armed.

  • Page 24: System Reset

    5.19 SYSTEM RESET To reset the Mobeye ThermoGuard to its factory settings: 1. Remove the batteries (and external power supply). 2. Press the outside button while reinserting the batteries. Keep it pressed for (about) another 5 seconds. 3. Release the button immediately after the LED starts to flash.

  • Page 25: Request List Of The Status, Settings And Signal Strength

    6. REQUEST LIST OF THE STATUS, SETTINGS AND SIGNAL STRENGTH Several lists and status reports can be retrieved by sending an SMS text message to the Mobeye ThermoGuard, from any telephone. Before sending the request, make sure the unit is in the program mode (please refer to 4.1).
  • Page 26 The signal strength of the used mobile network can be requested. If the network is weak, it is advised to use a SIM card of another network provider or an external GSM antenna (a Mobeye accessory). The GSM signal strength can be requested by sending following SMS text message:...

  • Page 27: Technical Messages And Status Feedback

    7. TECHNICAL MESSAGES AND STATUS FEEDBACK Technical messages In the event of technical issues the administrator receives an SMS message. Possible technical messages are: Message Reason Low batteries, external power Power is available, batteries need to be supply OK replaced. No external power supply, No external power supply, batteries are able to batteries OK...
  • Page 28 Status feedback LED pattern Status Required action Blinking green, 1 second Module not configured Configure at least one on / 1 second off telephone number. 1 green flash every 3 Module is switched on, No action required. seconds powered by batteries Green LED stays on Module is switched on, No action required.

  • Page 29: Mobeye Internet Portal

    8. MOBEYE INTERNET PORTAL The Mobeye ThermoGuard sends GSM messages to the preset contact persons. It is also possible to connect the system to the Mobeye Internet Portal. In this secured internet environment the Mobeye ThermoGuard system(s) can be administered.
  • Page 30 Publisher. Reprinting, even in summary, is prohibited. This user manual meets the technical requirements at the moment of printing. Changes in technology and equipment are reserved. © Copyright 2017 by Mobeye, version ThermoGuardEN170209...
