USER MANUAL
®
Mobeye
PowerGuard
CM2100
SW version 5.n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerGuard CM2100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mobeye PowerGuard CM2100

Summary of Contents for Mobeye PowerGuard CM2100

  • Page 1 USER MANUAL ® Mobeye PowerGuard CM2100 SW version 5.n...
  • Page 2 • Do not use in an environment where any inflammable gases, vapors or dust are present or could be present. ® • Repair of the device may only be carried out by people, trained for Mobeye repair. • If the device must be repaired, only original replacement components may be used. The ®...

  • Page 3: Table Of Contents

    Insert the batteries Connect an external power supply (optionally) Connect a sensor to the input (optionally) 4. Programming when using the Mobeye SIM and portal Sign up in the Mobeye Internet Portal Register the Mobeye SIM card Enter the program mode...
  • Page 4 Program at least one telephone number Programming the settings by SMS 7. List of SMS commands for programming with own SIM List of SMS commands Switching on/off Confirmation of the alarm message System reset SMS reports when using own SIM card Technical messages 8.

  • Page 5: General Description

    First of all you’ll have to choose a SIM card to place in the device. You can use the Mobeye SIM card or your own SIM card. The Mobeye SIM card provides access to the Mobeye Internet Portal. In this management environment the device is given additional functions such as online programming, status and history display, more options for forwarding messages and it will monitor test messages (keep alive).

  • Page 6: Standard Behaviour

    Mobeye Internet Portal, to be forwarded to the ‘alarm contacts’. - When one of the inputs is activated by a sensor, the Mobeye PowerGuard sends an alarm message to the Mobeye Internet Portal and calls the phone numbers programmed in by the user.

  • Page 7: Mobeye Powerguard With Own Sim Card

    - When the power is restored, the Mobeye PowerGuard sends a ‘power restored’ SMS text message. - When one of the inputs is activated by a sensor, the Mobeye PowerGuard sends an alarm SMS text message and calls the phone numbers programmed in by the user.

  • Page 8: Getting Started

    3. GETTING STARTED To get started with the Mobeye PowerGuard, at least the following steps need to be taken in the following order: 1. Insert the SIM card 2. Connect a sensor to the input 3. Insert the batteries 4. Connect an external power supply (optionally) 5.

  • Page 9: Connect A Sensor To The Input (Optionally)

    When using your own SIM card: Before installing the SIM card should have PIN code "0000", or PIN code removed. (A PIN code can be changed or removed by putting the SIM card in to any mobile phone and entering the 'security' menu.) NB: Make sure the SIM card is inserted before the batteries.

  • Page 10: Connect A Sensor To The Input (Optionally)

    The Mobeye PowerGuard is able to work on the batteries for a long time without an external power source and to monitor external sensors in the ‘low power’ mode.

  • Page 11: Programming When Using The Mobeye Sim And Portal

    You will receive an e-mail to confirm the new account. After confirmation login to the portal. If you do not receive this e-mail, check your spam box or ask Mobeye: (info@mobeye.eu). 4.2 REGISTER THE MOBEYE SIM CARD To activate the Mobeye SIM card in the Mobeye Internet Portal, choose ‘activate new SIM card’.

  • Page 12: Enter The Program Mode

    (factory) status and the batteries are inserted (so the LED is flashing), you activate the device in the Mobeye Internet Portal by clicking ‘Activate device’, which is written behind the registered SIM card. The unit will receive a message from the portal and the data exchange is started.

  • Page 13: Configuration And Synchronisation

    The device settings can be programmed in the Mobeye Internet Portal. In this way you prepare the settings, to be picked up by the device. Since the Mobeye device is leading in the communication between the portal and the device, the data synchronisation is done after: 1) any message to the portal (e.g.
  • Page 14 Options The configuration options (settings) can be changed in the Mobeye Internet Portal. Click ‘edit’ to change the settings. Type the installation code (factory setting is ‘1111’) to open the pop-up. Please see chapter 5 for the description of each setting.

  • Page 15: Switching On/Off

    4.7 SWITCHING ON/OFF After the previous steps the Mobeye PowerGuard is ready for use. It is armed (switched on) automatically. In order to switch off (disarm) the Mobeye PowerGuard: - Press the on/ off button at the upper side for 1 second. The green LED switches off to indicate the disarmed status.

  • Page 16: System Reset

    2. Reset the Mobeye PowerGuard 1. To delete the Mobeye PowerGuard from the Mobeye Internet Portal Delete the device from the Mobeye Internet Portal. The SIM card could be then reused for another Mobeye device, or the same device can be connected again.

  • Page 17: Possible Settings

    The Mobeye PowerGuard has many setting options that influence the behaviour of the module. If connected on the Mobeye Internet Portal, the settings are prepared in the portal (see chapter 4). If your own SIM card is used, programming is done via SMS commands (see chapter 6).

  • Page 18: Input Type

    5.4 INPUT TYPE The input type defines the character of the inputs IN1 and IN2. This can be Normally Open (NO) or Normally Closed (NC). If an input is set to "NO", the alarm will be triggered as soon as the terminals of the input are closed. If the input is set to NC, the alarm is triggered when the connection between the input terminals is broken.

  • Page 19: Alarm Repeat Time

    The time can be set between 0 and 999 minutes. As default, the delay time is set to "0". 5.10 POWER FAILURE MESSAGE If the Mobeye PowerGuard is powered externally and the power fails, it is able to make phone calls and/or send textual messages. There are three configuration options: Alert, Alarm, Off.

  • Page 20: Buttonlock

    "ON". 5.13 LOW POWER MODE A battery-powered Mobeye PowerGuard has the GSM module switched off in stand-by mode. It only switches on if it has to send a message. An externally powered unit always keeps the GSM module open (as factory default).

  • Page 21: Test Message

    (keep alive) to the Mobeye Internet Portal, to ensure the proper functioning of the unit. The test message will also be sent if the unit is disarmed. The Mobeye Internet Portal expects the test message and checks the timely receipt. The monitoring of the test messages follows the ‘management by exception’...

  • Page 22: Programming When Using Own Sim Card

    6.2 PROGRAM AT LEAST ONE TELEPHONE NUMBER The Mobeye PowerGuard is able to send messages up to 5 telephone numbers. The first telephone number (TEL1) belongs to the administrator. Technical messages (such as battery low) are sent to the administrator only.

  • Page 23: Programming The Settings By Sms

    NB: For this way of programming the number recognition in the administrator’s phone must be ‘on’. To program or change the administrator’s number by SMS command, please refer to the next section. 6.3 PROGRAMMING THE SETTINGS BY SMS When using your own SIM card, all settings are programmed in by SMS text messages: 1.

  • Page 24: List Of Sms Commands For Programming With Own Sim

    Change security code INSTCODE: 0000···9999 1111 Set telephone number for TEL1: Empty alarm messages TEL5: Delete telephone number DEL1 DEL5 Mobeye Identification text NAME: 20 characters Call on/off CALL: ON, OFF SMS on/off SMS: ON, OFF Input type input 1...

  • Page 25: Switching On/Off

    1111 del1 Be aware of the space between “1111” and the command. 7.2 SWITCHING ON/OFF After the previous steps the Mobeye PowerGuard is ready for use. It is armed (switched on) automatically. In order to switch off (disarm) the Mobeye PowerGuard: - Press the on/ off button at the upper side for 1 second.

  • Page 26: Confirmation Of The Alarm Message

    In order to switch on (arm) the Mobeye PowerGuard: - Press the on/ off button at the upper side for 1 second. The green LED blinks once every 3 seconds (battery-powered) or stays ‘on’ continuously (in case of an external power supply).

  • Page 27: Sms Reports When Using Own Sim Card

    Mobeye PowerGuard, from any telephone number. Before sending the request, make sure the unit is in the program mode (please refer to 6.1). Upon sending the command, the Mobeye PowerGuard returns an SMS text message to the originator of the request. The commands are case insensitive.

  • Page 28: Technical Messages

    7.6 TECHNICAL MESSAGES In the event of technical issues the administrator receives an SMS message. Possible technical messages are: Message Reason Low batteries, external power Power is available, batteries need to be supply OK replaced. No external power supply, No external power supply, batteries are able to batteries OK take over operation in low power mode.

  • Page 29: Status Feedback

    8. STATUS FEEDBACK LED pattern Status Required action Blinking green, 1 second Module not configured Configure at least one on / 1 second off telephone number. 1 green flash every 3 Module is switched on, No action required. seconds powered by batteries Green LED stays on Module is switched on, No action required.
  • Page 30 Publisher. Reprinting, even in summary, is prohibited. This user manual meets the technical requirements at the moment of printing. Changes in technology and equipment are reserved. © Copyright 2019 by Mobeye, version CM2100C-EN190901...
