Mobeye CM2500 User Manual

Panic button
Hide thumbs Also See for CM2500:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
USER MANUAL
®
Mobeye
Panic Button
CM2500
SW version 1.n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CM2500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mobeye CM2500

Summary of Contents for Mobeye CM2500

  • Page 1 USER MANUAL ® Mobeye Panic Button CM2500 SW version 1.n...
  • Page 2 In case of damage caused by disregarding the guidelines, the warranty expires. The user must regularly check the proper functioning of the device. The manufacturer cannot be ® held liable for any damage caused by any incorrect use or incorrect functioning of the Mobeye device. Safety guidelines •...

  • Page 3: Table Of Contents

    CONTENT General description Getting started Place a SIM card Place the batteries Enter the program mode Program at least one telephone number External emergency button and power supply Using an external emergency button Using external power Extended options Program mode The security code Programming the settings by SMS Possible General settings...

  • Page 4: General Description

    The factory settings of the Mobeye Panic Button cause following reactions: - In case of a panic alarm, the Mobeye Panic Button sends an alarm SMS text message and calls to the phone numbers as programmed. The SMS message contains the text ‘Mobeye Panic alarm’,...

  • Page 5: Getting Started

    2. GETTING STARTED To get started with the Mobeye Panic Button at least the following steps need to be taken in following order: 1. Place SIM card (with PIN code 0000 or without PIN code) 2. Place the batteries 3. Enter the program mode 4.
  • Page 6 NB : the Mobeye Panic Button is developed to run on batteries. As soon as the button is pressed during 1 second or longer, the module establishes GSM network connection. This could take approximately 15-20 seconds, depending on the local network strength. In order to shorten this time, the Mobeye Panic Button could be powered externally.

  • Page 7: External Emergency Button And Power Supply

    It is possible to connect external emergency buttons to the inputs. As soon as the button is pressed during at least one second, the Mobeye Panic Button reacts similar as after pressing the on/off button; it sends an SMS text message to the preset numbers and calls these numbers.

  • Page 8: Extended Options

    This paragraph describes the general settings for the Panic Button. 4.4.1 Phone numbers The Mobeye Panic Button is able to send alarm messages up to 5 phone numbers. The first telephone number (TEL1) belongs to the administrator. Only this number receives all system messages.

  • Page 9: Identification Text

    0031612345678). 4.4.2 Identification text It is possible to add a standard identification text (NAME) to all messages sent out by the Mobeye Panic Button. The alarm messages are a combination of the name and the alarm text. A user defined identification has a length of maximum 20 characters. The default identification text is ‘Mobeye’.

  • Page 10: Power Failure Sms Message

    SMS command interval test message: <CODE> TEST:xx 4.4.8 Power failure SMS message In case the Mobeye Panic Button is powered externally and the power fails it sends an SMS text message to the administrator. The message is only sent in case the unit is armed.

  • Page 11: Request Overview Of The Settings And Status

    Before sending the request, make sure the unit is in the program mode (please refer to 4.1). 5.1 STATUS REQUEST The status of the Mobeye Panic Button can be requested by sending an SMS with the content: <CODE> STATUS? Upon sending this request, the Mobeye Panic Button returns the status to the originator of the request.

  • Page 12: Technical Messages And Status Feedback

    6. TECHNICAL MESSAGES AND STATUS FEEDBACK Technical messages In case of technical issues the administrator receives an SMS message. Possible technical messages are: Message Reason Low batteries, external power supply Power is available, batteries need to be replaced No external power supply, batteries No external power supply, batteries are capable to take over operation in low power mode Low batteries, no external power...
  • Page 13 Publisher. Reprinting, even in summary, is prohibited. This user manual meets the technical requirements at the moment of printing. Changes in technology and equipment are reserved. © Copyright 2013 by Mobeye, version CM2500EN130121...
