  • Page 1 USER MANUAL Mobeye CM-Guard-42 ® CM4042 SW version 2.n...
  • Page 3 • Do not let it fall from height. • Do not use in an environment where any inflammable gases, vapors or dust are present or could be present. • Repair of the device may only be carried out by people, trained for Mobeye ® repair.

  • Page 4: Table Of Contents

    Connect a device to the output Insert the batteries Connect an external power supply Network connection and program mode 4. Programming and use with the Mobeye SIM and portal Sign up in the Mobeye Internet Portal Register the Mobeye SIM card Configuration and synchronisation...
  • Page 5 Switching the outputs on and off System reset SMS reports when using own SIM card Technical messages 8. Status feedback...

  • Page 7: General Description

    In order to activate the device, a few steps are to be followed. First of all, you need to insert a SIM card. With the Mobeye SIM card, the CM4042 uses the 4G LTE-M network. This network has a strong network coverage, deep penetrability in buildings and also works in remote areas.

  • Page 8: Standard Behaviour

    The Mobeye CM4042 with Mobeye SIM card and registered on the Mobeye Internet Portal, has the following behaviour as factory settings: - In case one of the inputs is activated by a sensor, the Mobeye CM4042 sends an alarm message to the Mobeye Internet Portal. The Portal forwards the alarm as push notification, call (spoken message), text message and/or e-mail to the ‘alarm contacts’.

  • Page 9: Mobeye Cm4042 With Own Sim Card

    The Mobeye CM4042, equipped with your own SIM card, has the following standard behavior as factory settings: - When one of the inputs is activated by a sensor, the Mobeye CM4042 sends an alarm SMS text message and (if the provider supports it) calls the phone numbers programmed in by the user.

  • Page 10: Getting Started

    3. GETTING STARTED To get started with the Mobeye CM4042, at least the following steps need to be taken in the following order: 1. Open the casing and insert the SIM card 2. Connect a sensor to the input 3. Connect a device to the output 4.

  • Page 11: Open The Casing And Insert The Sim Card

    Insert the SIM card into the module. When using the Mobeye SIM card: The Mobeye SIM card is PIN code secured and will only work in a Mobeye device. Please do not place it in another device. When using your own SIM card: An own SIM card has a “micro”...

  • Page 12: Connect A Sensor To The Input

    Connect the power adapter (or any other regulated 12-24V DC power supply) to the power input of the connector (press on the green pins to connect the wires). Mobeye EU adapter 10027 position - V+ to “+” black lead with white stripe left - Ground to “-“...

  • Page 13: Network Connection And Program Mode

    ‘low power’ mode, which means that it will only connect to the network to send an alarm message, test message or ‘battery low’ message. The Mobeye CM4042 can operate for a long time on batteries only. 3.6 NETWORK CONNECTION AND PROGRAM MODE After placing the batteries (and external power) the Mobeye CM4042 will search for the network.

  • Page 14: Programming And Use With The Mobeye Sim And Portal

    Follow the instructions on the screen. You will receive an e-mail to confirm the new account. After confirmation login on the portal. If you do not receive this e-mail, please check your spam box or ask Mobeye (info@mobeye.com). 4.2 REGISTER THE MOBEYE SIM CARD...

  • Page 15: Configuration And Synchronisation

    4.3 CONFIGURATION AND SYNCHRONISATION The device settings can be programmed in the Mobeye Internet Portal. In this way you prepare the settings, to be picked up by the device. Since the Mobeye device is leading in the communication between the portal and the device, the data synchronisation is done after: 1) any message to the portal (regular test message, alarm, low batteries).
  • Page 16 Device Settings The device settings can be changed via the Mobeye Internet Portal. To do this, click on the "edit" icon and type in the security code (factory setting is "1111"). See chapter 5 for the description per setting. After saving the new settings, they must be retrieved by the device (synchronized).

  • Page 17: How To Activate The Cm4042

    The message texts can be adapted to your own text. 4.5 HOW TO ACTIVATE THE CM4042 After the previous steps the Mobeye CM4042 is ready for use. It is armed automatically. In order to switch off (disarm) the Mobeye CM4042: - Press the button at the backside for 1 second.

  • Page 18: Switching The Outputs On And Off

    The security code is back to 1111 as well. The SIM card is now disconnected and is visible on the "Add device" screen. It can be used again in another (or the same) Mobeye device in combination with the portal.

  • Page 19: Possible Settings

    5. POSSIBLE SETTINGS The Mobeye CM4042 has many setting options that influence the behaviour of the module. If connected on the Mobeye Internet Portal, the settings are prepared in the portal (see chapter 4). If your own SIM card is used, programming is done via SMS commands (see chapter 7).

  • Page 20: Input Type

    When using your own SIM card: The Mobeye CM4042 can send regular test SMS messages (keep alive) to the first phone number (TEL1), to ensure the proper functioning of the unit. The test message function is only active if the unit is armed.

  • Page 21: Alarm Repeat Time

    In factory setting, the Mobeye CM4042 does not send a recovery message if an input alarm has been restored. It is possible to set a recovery message per input. In the Mobeye Internet Portal, the recovery text is visible (and can be changed) under the message texts, after an initial recovery message.

  • Page 22: Power Failure Delay Time

    "0". 5.14 AUTOMATIC ARMING / DISARMING The Mobeye CM4042 only works if the unit is armed, which is done via the on/off button. It is possible to automatically arm and disarm the unit, based on an arming and/or disarming time scheme. Two schemes can be entered, which can be assigned to the days in the week (e.g.

  • Page 23: Low Power Mode

    5.19 NOTIFICATION TO PRIVATE EMERGENCY CENTER The Mobeye CM4042 can send the reports to a control room using the standard SIA DC09 protocol. This requires the use of the Mobeye SIM/Portal.

  • Page 24: Programming When Using Own Sim Card

    If the CM4042 is connected to an external power supply, it has continuous network connection and is permanently in program mode. A battery-operated Mobeye CM4042 switches to the program mode after re- inserting the batteries or pressing the button at the back for 5 seconds.

  • Page 25: Programming The 4G Lte-M Settings

    LTE-M network. 6.4 PROGRAM AT LEAST ONE TELEPHONE NUMBER The Mobeye CM4042 is able to send messages up to 5 telephone numbers. The first telephone number (TEL1) is mandatory. This number will receive, next to alarm message, also system messages such as battery low and keep- alive message.

  • Page 26: List Of Sms Commands For Programming With Own Sim

    . . . TEL5: Delete telephone DEL1 number . . . DEL5 Identification text NAME: 20 characters Mobeye Interval ‘test SMS’ TEST: 0 ··· 30 (days) Time test message TESTTIME: hhmm Input type input 1 INPUTTYPE:1= NO, NC, OFF Input type input 2...
  • Page 27 Setting SMS command Options Default value Restore text input 2 TEXT8: 20 karakters Restore 2 Restore text input 3 TEXT9: 20 karakters Restore 3 Restore text input 4 TEXT10: 20 karakters Restore 4 Pulse time output 1 TO1: 0 ··· 9999 (sec) Pulse time output 2 TO2: 0 ···...

  • Page 28: How To Activate The Cm4042

    7.2 HOW TO ACTIVATE THE CM4042 After the previous steps the Mobeye CM4042 is ready for use. It is armed automatically. In order to switch off (disarm) the Mobeye CM4042: - Press the button at the backside for 1 second. The green LED switches off to indicate the disarmed status.

  • Page 29: System Reset

    • Note the space after code 1111. 7.4 SYSTEM RESET To reset the Mobeye CM4042 to its factory settings: 1. Remove the batteries and SIM card (and external power supply). 2. Press the outside button while reinserting the batteries. Keep it pressed for (about) another 5 seconds.

  • Page 30: Sms Reports When Using Own Sim Card

    Mobeye CM4042, from any telephone number. Before sending the request, make sure the unit is in the program mode (see 6.1). Upon sending the command, the Mobeye CM4042 returns an SMS text message to the originator of the request. The commands are case insensitive.

  • Page 31: Technical Messages

    7.6 TECHNICAL MESSAGES In the event of technical issues the telephone number programmed in at position 1 (TEL1) receives an SMS message. Possible technical messages are: Message Reason Low batteries, external power Power is available, batteries need to be replaced. supply OK No external power supply, No external power supply, batteries are able to take...

  • Page 32: Status Feedback

    Check SMS command. action 4 red flashes every 3 sec., Low batteries Replace both batteries. short green in between Flashes green/red Retrieving new firmware Wait fifteen minutes. simultaneously from Mobeye server Quickly flashing green Module exchanges data No action required with portal...
  • Page 33 This product is designed and manufactured in the Netherlands. For more information, visit www.mobeye.com. ® This manual is published by Mobeye All rights, the translation included are reserved. Any reproduction, either photocopy, microfilm or saved in an automated data dictionary, only after written approval of the Publisher.
