Summary of Contents for Mobeye i110
-
Page 1: User Manual
User manual ® Mobeye i110 SW version 7N... -
Page 3: Table Of Contents
4.13 Adjusting the temperature 4.14 Interval test message 4.15 Setting the current time and date 4.16 User code Advanced options Request settings Reset to factory settings Leave the menu Position of Mobeye Test GSM network strength Issue solving Technical data... - Page 4 In case of damage caused by disregarding the guidelines, the warranty becomes void. ® The user must regularly check the proper functioning of the Mobeye . The manufacturer cannot be held liable for any damage or loss caused by any ®...
-
Page 5: Introduction
The Mobeye i110 has the following features. Alarm notifications after movement detection In case of the detection of an intruder, the Mobeye i110 will send an SMS text message to your phone(s). The Mobeye i110 will also call the phone numbers in order to be sure the message is not missed. -
Page 6: To Get Ready In Four Steps
In this chapter these steps are explained. 2.1 STEP 1: SIM CARD To use the Mobeye i110 a SIM card from any network is needed. On this SIM card, the PIN code security needs to be disabled. If you have a SIM card with PIN code, you can disable this using any mobile phone and switch off the PIN code security. -
Page 7: Step 3: Program The Phone Numbers
Enter the phone number (e.g. 0712345678) Press “OK” The light turns green and a confirmation melody is played. The Mobeye i110 is ready to use. 2.4 STEP 4: CHECK THE SETTINGS The settings can be sent to the programmed telephone number as SMS text message. -
Page 8: Switching The Motion Detector On/Off
3. SWITCHING THE MOTION DETECTOR ON/OFF 3.1 SWITCHING ON To activate the Mobeye i110 movement detector with your personal installation code. Enter your 4 digit installation code (factory setting: “1111”) Press “OK” The light turns red shortly and an indication tone is started. This repetitive tone will last during the exit delay of 60 seconds. -
Page 9: Mobeye Settings
4. MOBEYE SETTINGS The Mobeye i110 settings can be changed via the keypad and SMS text messages. First the method of programming is discussed, next the explanation of the settings. 4.1 CONFIGURATION To change the settings, please follow these instructions: ... -
Page 10: Installation Code
This custom text (max. 20 characters) can be programmed by sending an SMS to the Mobeye i110. Changing the custom text cannot be done via the keypad, only via sending an SMS text message. -
Page 11: Telephone Numbers
The SMS alarm message and voice (‘alarm signal’) message can be sent to one or two telephone number. At least one telephone number must be entered in the Mobeye i110. The test messages and low battery messages are sent to the first programmed telephone number. -
Page 12: Entry Indication
After the entry delay, the siren can sound for two minutes. At the same time the SMS text messages and telephone calls will be sent. At soon as the Mobeye is switched off, the siren will stop. The siren is set to silent as the factory default. -
Page 13: Interval Test Message
(CODE MENU 10 OK). 4.16 USER CODE The Mobeye i110 offers the possibility to set a personal 4-digit user code, for just arming and disarming the system. It is not possible to change the settings with the user code. -
Page 14: Advanced Options
Within ca. 30 seconds the first phone number will receive the list with settings. 5.2 RESET TO FACTORY SETTINGS It is possible to reset the Mobeye i110 to factory settings. Enter your 4 digit installation code (factory setting: “1111”) Press “menu”... -
Page 15: Position Of Mobeye
It can be mounted to the wall, put down on its side in a cabinet, put down with its sensor upward or downward. If you want to hang the Mobeye i110, the pre-punched holes can be opened, in order to hang it on screws. -
Page 16: Test Gsm Network Strength
“OK” twice. Warning In the event of a weak signal, the Mobeye i110 can still be used, but there is a risk that messages cannot be sent or will be received with a delay. In... -
Page 17: Issue Solving
You do not receive an Telephone number is Re-program the SMS with the settings. not correct. telephone number Change the menunr.06 to ‘01’. For other questions, please refer to the site www.mobeye.eu... -
Page 18: Technical Data
• Batteries: 4 x CR123 Lithium 3.0 V • Power: 50 μA, short peaks of max. 2 A Support For support on technical problems regarding Mobeye i110 please contact info@mobeye.eu. CONRAD IM INTERNET http://www.conrad.de This manual is published by Mobeye. -
Page 19: Declaration Of Conformity
Declaration of Conformity Herewith we, Mobeye, declare that the product Mobeye i-110 is in compliance with the essential requirements of the following European standards / EU Directives: Directive 73/23/EEC (low voltage directive) Directive IEC/EN 50130 Electromagnetic compatibility Directive 1995/5/EC R&TTE (Radio & Telecommunications...
