USER MANUAL
®
Mobeye
CombiGuard
CM2600
SW version 5.n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CombiGuard CM2600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mobeye CombiGuard CM2600

Summary of Contents for Mobeye CombiGuard CM2600

  • Page 1 USER MANUAL ® Mobeye CombiGuard CM2600 SW version 5.n...
  • Page 2 • Do not let it fall from height. • Do not use in an environment where any inflammable gases, vapors or dust are present or could be present. • Repair of the device may only be carried out by people, trained for Mobeye ® repair.

  • Page 3: Table Of Contents

    Insert the batteries Connect an external power supply (optionally) Connect a sensor to the inputs (optionally) 4. Programming when using the Mobeye SIM and portal Sign up in the Mobeye Internet Portal Register the Mobeye SIM card Enter the program mode...
  • Page 4 5.15 Buttonlock 5.16 Low power mode 5.17 Pulse time output 5.18 Output behaviour 5.19 Test message 6. Programming when using own SIM card Program mode Programming the settings by SMS Program at least one telephone number Program the settings 7. List of SMS commands for programming with own SIM List of SMS commands Switching on/off Confirmation of the alarm message...

  • Page 5: General Description

    First of all you’ll have to choose a SIM card to place in the device. You can use the Mobeye SIM card or your own SIM card. The Mobeye SIM card provides access to the Mobeye Internet Portal. In this management environment the device is given additional functions such as online programming, status and history display, more options for forwarding messages and it will monitor test messages (keep alive).

  • Page 6: Standard Behaviour

    As soon as the voltage recovers a recovery message is sent. - If the second input is activated by a sensor, the Mobeye CombiGuard sends an alarm message to the Mobeye Internet Portal and calls the phone numbers programmed in by the user.

  • Page 7: Mobeye Combiguard With Own Sim Card

    ‘service’ contacts. Chapter 5 describes how to influence the standard behaviour. As described, the Mobeye CombiGuard will, in addition to calling in the event of an alarm, send various messages to the Mobeye Internet Portal. This is done via data traffic where possible.
  • Page 8 - When the batteries need to be replaced, the Mobeye CombiGuard sends a ‘low battery’ SMS text message to the first telephone number (administrator). - When an external power supply is used and a power failure occurs, the Mobeye CombiGuard sends a ‘power failure’ SMS text message to the set telephone numbers and calls them.

  • Page 9: Getting Started

    3. GETTING STARTED To get started with the Mobeye CombiGuard, at least the following steps need to be taken in the following order: 1. Insert the SIM card 2. Connect the water sensor (optionally) 3. Connect the temperature sensor (optionally) 4.

  • Page 10: Connect The Water Sensor To The Left Input

    When using your own SIM card: Before installing the SIM card should have PIN code "0000", or PIN code removed. (A PIN code can be changed or removed by putting the SIM card in to any mobile phone and entering the 'security' menu.) NB: Make sure the SIM card is inserted before the batteries.

  • Page 11: Connect A (Boat) Battery To The Input

    12 VDC. The required switching voltage of the relay depends on the device that is connected. NOTE: The output does function when the Mobeye ShipGuard is battery-operated. 3.6 INSERT THE BATTERIES Insert the two batteries (CR123) in the module.

  • Page 12: Connect An External Power Supply (Optionally)

    3.7 CONNECT AN EXTERNAL POWER SUPPLY (OPTIONALLY) Although the Mobeye CombiGuard is designed to run on batteries, it is possible to use an external power supply. In this mode the module is always connected with the GSM network and therefore always in program mode. When the power fails, the batteries take over and a power failure alarm message is sent.
  • Page 13 (AN), please refer to paragraph 5.4. If you require the sensor to be activated for a shorter or longer period before triggering an alarm, refer to 5.6. Input 2 can also be set to NO or NC.

  • Page 14: Programming When Using The Mobeye Sim And Portal

    You will receive an e-mail to confirm the new account. After confirmation login on the portal. If you do not receive this e-mail, please check your spam box or ask Mobeye (info@mobeye.com). 4.2 REGISTER THE MOBEYE SIM CARD...

  • Page 15: Enter The Program Mode

    3 seconds. 4.4 ACTIVATE THE DEVICE IN THE PORTAL If the LED on the outside flashes once per second, you activate the device in the Mobeye Internet Portal by clicking ‘Activate device’, which is written behind the registered SIM card. Contract SIM card + portal “Monitoring”...

  • Page 16: Configuration And Synchronisation

    The device settings can be programmed in the Mobeye Internet Portal. In this way you prepare the settings, to be picked up by the device. Since the Mobeye device is leading in the communication between the portal and the device, the data synchronisation is done after: 1) any message to the portal (e.g.
  • Page 17 Device Settings The device settings can be changed via the Mobeye Internet Portal. To do this, click on the "edit" icon and type in the security code (factory setting is "1111"). See chapter 5 for the description per setting. After saving the new settings, they must be retrieved by the device (synchronized).

  • Page 18: Switching On/Off

    4.7 SWITCHING ON/OFF After the previous steps the Mobeye CombiGuard is ready for use. It is armed (switched on) automatically. In order to switch off (disarm) the Mobeye CombiGuard: - Press the on/ off button at the upper side for 1 second. The green LED switches off to indicate the disarmed status.

  • Page 19: System Reset

    The security code is back to factory settings as well. The SIM card is now disconnected and is visible on the "Add device" screen. The SIM card can be used again in another (or the same) Mobeye device in combination with the portal.

  • Page 20: Possible Settings

    The Mobeye CombiGuard has many setting options that influence the behaviour of the module. If connected on the Mobeye Internet Portal, the settings are prepared in the portal (see chapter 4). If your own SIM card is used, programming is done via SMS commands (see chapter 10).

  • Page 21: Input Type

    5.4 INPUT TYPE The input type defines the character of input IN1 and IN2. This can be Normally Open (NO), Normally Closed (NC) or Analogue (AN). If an input is set to "NO", the alarm will be triggered as soon as the terminals of the input are closed. If the input is set to “NC”, the alarm is triggered when the connection between the input terminals is broken.

  • Page 22: Set A Minimum And/Or Maximum Temperature Limit

    The adjusted temperature will be used in the measurement and reports. Example: the Mobeye CombiGuard measures 13 °C. Actual ambient temperature is measured as 13,5 °C. To adjust this difference, +0,5 degrees shall be programmed.

  • Page 23: Power Failure Message

    5.12 POWER FAILURE MESSAGE If the Mobeye CombiGuard is powered externally and the power fails, it is able to make phone calls and/or send textual messages. There are three configuration options: Alert, Alarm, Off. Mobeye SIM/Portal Own SIM Alert Message via portal...

  • Page 24: Buttonlock

    "ON". 5.16 LOW POWER MODE A battery-powered Mobeye CombiGuard has the GSM module switched off in stand- by mode. It only switches on if it has to send a message. An externally powered unit always keeps the GSM module open (as factory default).

  • Page 25: Output Behaviour

    The message will update the temperature and voltage in the status block. The test message will also be sent if the unit is disarmed. The Mobeye Internet Portal expects the test message and checks the timely receipt. The monitoring of the test messages follows the ‘management by exception’...

  • Page 26: Programming When Using Own Sim Card

    In the situation that the CombiGuard is connected to an external power supply, it has continuous network connection and the unit is permanently in program mode. A battery-operated Mobeye CombiGuard switches to the program mode after pressing the on/off button for 5 seconds until the LED starts flashing. Alternatively the batteries are re-inserted.

  • Page 27: Programming The Settings By Sms

    In chapter 7.1 all possible SMS commands are listed. 6.3 PROGRAM AT LEAST ONE TELEPHONE NUMBER The Mobeye CombiGuard is able to send messages up to 5 telephone numbers. The first telephone number (TEL1) belongs to the administrator. Technical messages (such as battery low) are sent to the administrator only. Without the administrator’s phone number, the Mobeye CombiGuard cannot function.

  • Page 28: Program The Settings

    unit will recognize this number and store it as administrator (TEL1). The administrator will receive a confirmation SMS text message including the security code. This code is needed to program the other settings in the unit. NB: For this way of programming the number recognition in the administrator’s phone must be ‘on’.

  • Page 29: List Of Sms Commands For Programming With Own Sim

    Set telephone number for TEL1: Empty alarm messages TEL5: Delete telephone number DEL1 DEL5 Identification text NAME: 20 characters Mobeye Call on/off CALL: ON, OFF SMS on/off SMS: ON, OFF Lower limit temperature LTL: -35··· 70 (ºC) Upper limit temperature HTL: -35···...
  • Page 30 Setting SMS Command Options Default value Alarm repeat time REPEAT: 0···24 (hrs) Text at too low TEXT1: 20 characters Temperature temperature sensor too low: Text at too high TEXT2: 20 characters Temperature temperature sensor too high: Text temperature TEXT3: 20 characters Temperature restoration Alarm text NO/NC input 1 TEXT4:...
  • Page 31 Setting SMS Command Options Default value SMS, SMSCALL Pulse time output TO1: 0···9999 (sec) Interval ‘test SMS’ TEST: 0···30 (days) Time test message TESTTIME: hhmm Examples: Set phone number 1: 1111 TEL1:0712345678 Delete phone number 1: 1111 del1 Be aware of the space between “1111” and the command.

  • Page 32: Switching On/Off

    7.2 SWITCHING ON/OFF After the previous steps the Mobeye CombiGuard is ready for use. It is armed (switched on) automatically. In order to switch off (disarm) the Mobeye CombiGuard: - Press the on/ off button at the upper side for 1 second. The green LED switches off to indicate the disarmed status.

  • Page 33: System Reset

    The commands are case insensitive. ACTUAL TEMPERATURE The actual temperature values as measured by the Mobeye CombiGuard can be requested by sending an SMS text message with the content (without code): STATUS REQUEST The status can be requested by sending following SMS text message.
  • Page 34 The signal strength of the used mobile network can be requested. If the network is weak, it is advised to use a SIM card of another network provider or an external GSM antenna (a Mobeye accessory). The GSM signal strength can be requested by sending following SMS text message:...

  • Page 35: Technical Messages

    7.6 TECHNICAL MESSAGES In the event of technical issues the administrator receives an SMS message. Possible technical messages are: Message Reason Low batteries, external power Power is available, batteries need to be supply OK replaced. No external power supply, No external power supply, batteries are able to batteries OK take over operation in low power mode.

  • Page 36: Status Feedback

    8. STATUS FEEDBACK LED pattern Status Required action Blinking green, 1 second Module not configured Configure at least one on / 1 second off telephone number. 1 green flash every 3 Module is switched on, No action required. seconds powered by batteries Green LED stays on Module is switched on, No action required.
  • Page 37 Publisher. Reprinting, even in summary, is prohibited. This user manual meets the technical requirements at the moment of printing. Changes in technology and equipment are reserved. © Copyright 2019 by Mobeye, version CM2600C-EN191111...
