Quick Guide
1 1
Parameter
1-26 Torque
nominal do
Motor
1-30 Resistênci
a do Estator
(Rs)
1-37 Indutânci
a do eixo-d
(Ld)
1-39 Pólos do
Motor
1-40 Força
Contra Eletro-
motriz em
1000RPM
1-73 Flying
Start
3-41 Ramp 1
Ramp Up
Time
3-42 Ramp 1
Ramp Down
Time
4-12 Motor
Speed Low
Limit [Hz]
20
VLT
Range Default Function
0.1-1000.0 Size related This parameter is
available only
when
1-10 Construção
do Motor Design
is set to [1] PM,
non-salient SPM.
NOTE
Changing this
parameter
affects settings
of other
parameters
.
0.000-99.990 Size related Set the stator
resistance value.
0-1000 Size related Enter the value
of the d-axis
inductance.
Obtain the value
from the
permanent
magnet motor
data sheet. The
de-axis
inductance
cannot be found
by performing an
AMA.
2-100 4 Enter the number
of motor poles.
10-9000 Size related Line-Line RMS
back EMF voltage
at 1000 RPM.
[0] Disabled 0 Select Enable to
[1] Enabled enable the
frequency
converter to
catch a spinning
motor.
0.05-3600.0 s Size related Ramp up time
from 0 to rated
1-23 Motor
Frequency.
0.05-3600.0 s Size related Ramp down time
from rated
1-23 Motor
Frequency to 0.
0.0-400 Hz 0.0 Hz Enter the
minimum limit
for low speed.
MG18F402 - VLT
®
HVAC Basic Drive Cascade Controller Quick Guide
Parameter
4-14 Motor
Speed High
Limit [Hz]
4-19 Freqüênc
ia Máx. de
Saída
Table 1.19 Quick Menu Motor Set-up
Changes Made
Changes Made lists all parameters changed from default
settings.
•
The list shows only parameters which have been
changed in the current edit-setup.
•
Parameters which have been reset to default
values are not listed.
•
The message 'Empty' indicates that no
parameters have been changed.
To change parameter settings
1. Press [Menu] key to enter the Quick Menu until
indicator in display is placed above Quick Menu.
2.
Press [
motor setup or changes made, then press [OK].
3.
Press [
in the Quick Menu.
4. Press [OK] to select a parameter.
5.
Press [
setting.
6. Press [OK] to accept the change.
7. Press either [Back] twice to enter "Status", or
press [Menu] once to enter "Main Menu".
The Main Menu accesses all parameters.
1. Press [Menu] key until indicator in display is
placed above "Main Menu".
2.
Press [
groups.
3. Press [OK] to select a parameter group.
4.
Press [
in the specific group.
5. Press [OK] to select the parameter.
6.
Press [
®
is a registered Danfoss trademark
Range Default Function
0.0-400 Hz 65 Enter the
maximum limit
for high speed.
0-400 Size related Enter the
maximum output
frequency value.
▲ ▼
] [ ] to select wizard, closed loop setup,
▲ ▼
] [ ] to browse through the parameters
▲ ▼
] [ ] to change the value of a parameter
▲ ▼
] [ ] to browse through the parameter
▲ ▼
] [ ] to browse through the parameters
▲ ▼
] [ ] to set/change the parameter value.
