Quick Guide
1 1
Parameter
0-03 Regional Settings
0-06 GridType
1-00 Configuration Mode
1-20 Motor Power
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
1-26 Torque nominal do Motor
1-29 Automatic Motor Adaption
(AMA)
1-30 Resistência do Estator (Rs)
1-37 Indutância do eixo-d (Ld)
1-39 Pólos do Motor
1-40 Força Contra Eletromotriz em
1000RPM
1-73 Flying Start
3-02 Minimum Reference
3-03 Maximum Reference
3-10 Preset Reference
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time
4-12 Motor Speed Low Limit [Hz]
4-14 Motor Speed High Limit [Hz]
4-19 Freqüência Máx. de Saída
6-29 Terminal 54 mode
6-20 Terminal 54 Low Voltage
18
®
VLT HVAC Basic Drive Cascade Controller Quick Guide
Range
[0] International
[1] US
[0] -[[132] see start -up wizard
for open loop application
[0] Open loop
[3] Closed loop
0.09-110 kW
50.0-1000.0 V
20.0-400.0 Hz
0.0 -10000.00 A
100.0-9999.0 RPM
0.1-1000.0
0.000-99.990
0-1000
2-100
10-9000
[0] Disabled
[1] Enabled
-4999-4999
-4999-4999
-100-100%
0.05-3600.0 s
0.05-3600.0 s
0.0-400 Hz
0-400 Hz
0-400
[0] Current
[1] Voltage
0-10 V
®
MG18F402 - VLT is a registered Danfoss trademark
Default Function
0
Size selected Select operating mode for restart upon
reconnection of the frequency converter to
mains voltage after power down.
0 Change this parameter to Closed loop.
Size related Enter motor power from nameplate data.
Size related Enter motor voltage from nameplate data.
Size related Enter motor frequency from nameplate data.
Size related Enter motor current from nameplate data.
Size related Enter motor nominal speed from nameplate
data.
Size related This parameter is available only when
1-10 Construção do Motor Design is set to [1]
PM, non-salient SPM.
NOTE
Changing this parameter affects settings
of other parameters.
Off Performing an AMA optimizes motor
performance.
Size related Set the stator resistance value.
Size related Enter the value of the d-axis inductance.
Obtain the value from the permanent magnet
motor data sheet. The de-axis inductance
cannot be found by performing an AMA.
4 Enter the number of motor poles.
Size related Line-Line RMS back EMF voltage at 1000 RPM.
0 Select [1] Enable to enable the frequency
converter to catch a spinning motor. I.e. fan
applications. When PM is selected, Flying Start
is enabled.
0 The minimum reference is the lowest value
obtainable by summing all references.
50 The maximum reference is the highest value
obtainable by summing all references.
0 Enter the set point.
Size related Ramp up time from 0 to rated 1-23 Motor
Frequency if Asynchron motor is selected;
ramp up time from 0 to 1-25 Motor Nominal
Speed if PM motor is selected".
Size related Ramp down time from rated 1-23 Motor
Frequency to 0 if Asynchron motor is selected;
ramp down time from 1-25 Motor Nominal
Speed to 0 if PM motor is selected.
0.0 Hz Enter the minimum limit for low speed.
65 Hz Enter the minimum limit for high speed.
Size related Enter the maximum output frequency value.
1 Select if terminal 54 is used for current- or
voltage input.
0.07 V Enter the voltage that corresponds to the low
reference value.
