INSTRUCTIONS FOR USE - OM 36
2.

INSTRUMENT DESCRIPTION

DESCRIPTION
The OM 36 model series are simple 3 1/2 digit panel instruments, which are manufactured in the following alternatives:
DC
DC voltmeter/ammeter
AC
AC voltmeter/ammeter
PM
Process monitor
OHM
Ohmmeter
RTD
Thermometer for sensors Pt 100
The instrument is based on a simple converter, which secures high accuracy and stability.
ADJUSTABLE DISPLAY PROJECTION
Setting
by potentiometers under the front panel (in the range of approx. ±10 %)
Projection
±1999
OPERATION
The instrument is designed for simple measurement without further control.
Placement of the decimal point is selectable by shorting link under the front panel.
EXTENSION
Excitation is suitable for feeding of sensors and transducers. It has a galvanic isolation with continuously adjustable value
in the range of 2...24 VDC.
Analogue outputs will find their place in applications where further evaluating or processing of measured data in external
devices is required. We offer several types of current or voltage non-isolated outputs. The value of analogue output corre-
sponds with the input signal.
4
